Wurth Elektronik WR-TBL Series PCB Terminal Block 2-Contact 5.08 mm Pitch 1 Row 300V 20A Push-in Connection 691406510002B

Wurth Elektronik 691406510002B WR-TBL Series PCB Terminal Block is a high-performance push-in spring connector engineered for reliable electronic connections in industrial and commercial PCB assemblies. Ideal for applications requiring robust and compact pluggable terminal solutions.

This terminal block features a 2-contact configuration and a 5.08 mm pitch arranged in a single-row layout to optimize space on printed circuit boards. Constructed with a polyamide housing material, it ensures electrical insulation, mechanical strength, and thermal stability with an operating temperature range from -40 °C to +105 °C. The green-colored housing aids easy visual identification during wiring and assembly processes.

The connector supports conductors from 0.2 mm² to 2.5 mm², compatible with both solid and stranded wires. Its push-in wire connection method facilitates quick and reliable contact without the need for screws, improving assembly efficiency while maintaining excellent contact resistance rated at 20 milliohms. The terminal block is rated for voltages up to 300V and currents up to 20A, making it suitable for a wide range of electronic and electrical industrial applications.

Physical dimensions of the terminal block are compact, with a length of 11.56 mm, width of 14.4 mm, and depth of 13.5 mm, facilitating space-conscious PCB layouts. The product meets UL94 V-0 flammability standards for insulators, ensuring safe usage in demanding environments. It is manufactured in China and part of the trusted WR-TBL series from Wurth Elektronik.

This component finds use extensively in industrial machinery, automation systems, power supplies, HVAC controls, and various commercial electronic devices requiring secure PCB wire connections.

Features a 2-contact configuration suitable for PCB mounting. Maintains a pitch of 5.08 mm and single-row design for compact installation. Constructed with polyamide housing for enhanced durability and electrical insulation.

Supports wire sizes ranging from 0.2 mm² to 2.5 mm² solid or stranded conductors. Operates safely at voltages up to 300V and currents up to 20A. Designed for horizontal orientation with push-in wire connection method. Bright green color aids visual identification in assemblies.

Compact dimensions with length 11.56 mm, width 14.4 mm, depth 13.5 mm. Operating temperature range from -40 °C to +105 °C. Contact resistance rated at 20 mΩ ensuring reliable conductivity. Compliance with UL94 V-0 flammability rating for insulator materials.
