Weidmüller LSF Series PCB Terminal Block 8-Contact 7.5 mm Pitch 1 Row 800V Push-In Connection 1824940000
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 800V |
| Brand | Weidmüller |
| Colour | Black |
| Orientation | 90° |
| Current | 17.5A |
| Depth | 14.75mm |
| Width | 56.7mm |
| Housing Material | Fibreglass Liquid Crystal Polymer |
| Series | LSF |
| Number of Rows | 1 |
| Pitch | 7.5mm |
| Standards/Approvals | IEC 61984, IEC 60664-1 |
| Number of Contacts | 8 |
| Minimum Wire Size mm² | 0.2mm² |
| Maximum Wire Size mm² | 1.5mm² |
| Minimum Wire Size AWG | 28AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Push-in |
Key Features
- Enables reliable connection of solid wires and wire-end ferrules without tools.
- Supports current up to 17.5 A with 800 V voltage rating.
- Constructed with durable fibreglass liquid crystal polymer housing material.
- Designed for 90° wire orientation and automatic SMT reflow soldering processes.
- Compact form factor with dimensions 56.7 mm (width) x 14.75 mm (depth).
- Complies with IEC 61984 and IEC 60664-1 standards for safety and quality.
- Compatible with wire sizes from 0.2 mm² (28 AWG) up to 1.5 mm² (14 AWG).
- Features colored push buttons for clear marking of potentials and clamping points.
Product Description
Weidmüller 1824940000 LSF Series PCB Terminal Block is a high-quality 8-contact connector designed specifically for printed circuit board (PCB) applications. With a pitch of 7.5 mm and a single-row configuration, this terminal block offers efficient, compact connections suitable for various electrical and electronic assemblies.
The terminal block features a robust housing made from fibreglass liquid crystal polymer, providing excellent mechanical and thermal resistance. It supports an electrical current rating of 17.5 A and voltage up to 800 V, ensuring reliable performance in demanding industrial environments.
Its innovative push-in wire connection system enables quick and tool-free wiring of solid conductors and wire-end ferrules, improving installation speed and reducing assembly errors. The wire connection operates at a 90° orientation, matching typical PCB layouts, and the block is fully compatible with automated reflow soldering (SMT) techniques for streamlined manufacturing.
Color-coded push buttons mark potentials and clamping points clearly, facilitating easy identification and safe operation. The product complies with internationally recognized IEC 61984 and IEC 60664-1 standards, assuring safety, reliability, and compliance with industry norms.
Applications include industrial electronics, laboratory instrumentation, control cabinets, and power distribution modules requiring secure PCB wiring solutions. The compact dimensions (56.7 mm width and 14.75 mm depth) enable multi-layer designs up to 72 poles, optimizing space efficiency.
Enables reliable connection of solid wires and wire-end ferrules without tools. Supports current up to 17.5 A with 800 V voltage rating. Constructed with durable fibreglass liquid crystal polymer housing material. Designed for 90° wire orientation and automatic SMT reflow soldering processes.
Compact form factor with dimensions 56.7 mm (width) x 14.75 mm (depth). Complies with IEC 61984 and IEC 60664-1 standards for safety and quality. Compatible with wire sizes from 0.2 mm² (28 AWG) up to 1.5 mm² (14 AWG). Features colored push buttons for clear marking of potentials and clamping points.
Explore a comprehensive range of Weidmüller PCB Terminal Blocks and connectors at EnvMart for reliable and professional electrical assembly solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a voltage rating of 800 V, making it suitable for high-voltage applications.
This model supports a current capacity of up to 17.5 A, ensuring reliable performance in various applications.
It is compatible with wire sizes ranging from 0.2 mm² (28 AWG) to 1.5 mm² (14 AWG).
The dimensions of this model are 56.7 mm in width and 14.75 mm in depth, allowing for compact installations.
The housing is constructed from fibreglass liquid crystal polymer, providing good mechanical and thermal resistance.
It features a push-in connection method, allowing for quick and tool-free wiring of solid conductors and wire-end ferrules.
The pitch of this terminal block is 7.5 mm, suitable for various PCB layouts.
Yes, it complies with IEC 61984 and IEC 60664-1 standards for safety and quality assurance.
This model is designed for a 90° wire orientation, which matches typical PCB layouts.
It is suitable for applications in industrial electronics, laboratory instrumentation, control cabinets, and power distribution modules.
Yes, it has colored push buttons that clearly mark potentials and clamping points for easy identification.
This model features 8 contacts, allowing for multiple connections in a single unit.
