Amphenol Communications Solutions RJ45 Connector Female PCB Cat5e Shielded Right Angle 2 Port 8 Way RJSGE4
Specifications
| Country of Origin | China |
|---|---|
| Brand | Amphenol Communications Solutions |
| Orientation | Right Angle |
| Model | RJSGE4 |
| IP Rating | IP20 |
| Connector Type | Modular Jack |
| Number Of Ways | 8 |
| Mount Type | PCB |
| Contact Material | Phosphor Bronze |
| Series | RJSGE4 |
| Number Of Ports | 2 |
| Termination Type | Press Fit |
| Maximum Operating Temperature | 85°C |
| Minimum Operating Temperature | -55°C |
| Shield Type | Shielded |
| Contact Plating | Gold over Nickel |
| Connector Gender | Female |
| LAN Category | Cat5e |
| Ethernet Connector Type | RJ45 |
Key Features
- Supports 1G and 2.5G Ethernet transmission speeds up to 100MHz.
- Features a unique 2x2 four port press fit modular jack design.
- Constructed with phosphor bronze contacts plated with gold over nickel for excellent conductivity.
- Shielded design with right angle orientation for PCB mounting.
- Includes LED indicators for port status monitoring.
- Press fit termination ensures secure, solderless connection to PCB.
- Operating temperature range from -55°C to 85°C for industrial reliability.
- IP20 rated protection against solid objects with no liquid ingress protection.
Product Description
Amphenol Communications Solutions RJSGE4 RJ45 Connector Female PCB Cat5e Shielded Right Angle 2 Port 8 Way is a high-performance Ethernet connector designed for industrial and telecommunications applications. It meets Cat5e specifications according to EIA-568-C.2 standards and supports transmission rates suitable for 1G and 2.5G Ethernet up to 100MHz frequency.
This modular jack features a unique 2x2, four-port, press fit design, facilitating easy and reliable mounting on printed circuit boards (PCB) without soldering. The connector is shielded to reduce electromagnetic interference and improve signal integrity in demanding environments.
Contacts are made of phosphor bronze with gold over nickel plating, providing durability and excellent conductivity. The right angle orientation optimizes PCB space utilization. LED indicators enhance operational visibility for network diagnostics.
The connector operates reliably within a temperature range of -55°C to 85°C, suitable for various industrial and commercial electronic equipment. It has an IP20 rating, offering protection against penetration by solid objects larger than 12 mm but does not provide liquid ingress protection.
This product is RoHS compliant, ensuring it meets environmental and safety regulations. It is manufactured in China and is ideal for use in networking equipment, telecom hardware, industrial automation, and other electronic manufacturing applications.
Supports 1G and 2.5G Ethernet transmission speeds up to 100MHz. Unique 2x2 four port press fit modular jack design. Phosphor bronze contacts with gold over nickel plating. Shielded design with right angle orientation for PCB mounting.
LED status indicators included for monitoring. Press fit termination for secure PCB connection. Operating temperature range -55°C to 85°C for industrial use. IP20 rated for protection against solid objects. Browse the extensive selection of Ethernet Connectors and related networking components on EnvMart for high-quality industrial and commercial solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating temperature for this model is 85°C.
It uses a press fit termination type for secure connection to the PCB without soldering.
This connector features 2 ports.
The connector has an IP20 rating, providing protection against solid objects larger than 12 mm but no liquid ingress protection.
This model has a right angle orientation, optimizing PCB space utilization.
The contacts are made of phosphor bronze and are plated with gold over nickel for excellent conductivity.
It supports Ethernet transmission speeds of 1G and 2.5G up to a frequency of 100MHz.
Yes, it is RoHS compliant, ensuring it meets environmental and safety regulations.
The minimum operating temperature is -55°C.
It is a modular jack type connector designed for use with Cat5e specifications.
This connector is manufactured in China.
