Molex Micro-Fit 3.0 Series Right Angle Surface PCB Header 6 Contacts 3 mm Pitch 1 Row Shrouded 43650-0613

Molex 43650-0613 Micro-Fit 3.0 Series Right Angle Surface PCB Header is a highly reliable electronic component designed to provide a compact power distribution solution. This connector features 6 contacts arranged in a single row with a 3 mm pitch, ensuring a small footprint while accommodating up to 5A of current.

The housing is made from high temperature thermoplastic material compliant with UL 94V-0, capable of withstanding temperatures up to 265°C during IR reflow soldering ensuring robustness during manufacturing. The design includes positive latching with a locking ramp on the housing to secure mating connections and prevent accidental disconnection, enhancing operational reliability.

The PCB header uses a wire-to-board connector system with a right angle orientation, optimized for surface mounting with integrated solder tabs providing mechanical stability. Contacts are made of brass and plated with gold, offering excellent conductivity and corrosion resistance. The contacts are fully isolated inside the housing to minimize arcing, which ensures electrical safety and longevity.

This Micro-Fit 3.0 Series connector operates reliably over a wide temperature range from -40°C to 125°C. The product meets Glow Wire compliance, making it suitable for applications requiring enhanced safety standards.

Typical industrial applications include military commercial off-the-shelf (COTS) components, solar power systems, consumer household appliances such as dryers and refrigerators, data communication devices like routers and servers, medical equipment, telecommunications, and gaming terminals.

High current carrying capacity in a compact form factor. High temperature resistant housings for IR reflow soldering processes. Positive latching mechanism for secure mating. Gold plated brass contacts for durability and electrical reliability.

Solder tabs enable strong surface mounting on PCB. Wide operating temperature from -40°C to 125°C. Fully isolated terminals to reduce electrical arcing. Glow Wire compliant for safety. Versatile applications in military, solar, consumer products, communications, medical, and gaming.
