TE Connectivity Pluggable Terminal Block 10-Contact 5.08 mm Pitch 1 Row 300V AC 15A 1-796634-0

TE Connectivity 1-796634-0 Pluggable Terminal Block is a 10-contact, 5.08 mm pitch, single-row connector designed for use in electronic component assemblies requiring secure and reliable PCB connections. The terminal block supports a voltage rating of 300V AC and a current capacity of 15A, suitable for various industrial and commercial electrical applications.

The connector features a robust green polyamide housing, providing excellent insulation properties and resistance to deteriorating environmental conditions. It is designed with a right-angle orientation to enable side stacking and easy PCB mounting, making it ideal for compact circuit designs.

This model accommodates wire sizes ranging from 30 AWG (0.05 mm²) up to 12 AWG (3 mm²) using M3 screw terminals that provide a secure wire connection. The terminal block is supplied with open screws to streamline assembly and save time during installation. It is suitable for use in corrosive environments, ensuring long-term durability and reliability.

The product meets established industry safety and quality standards, including RoHS compliance, UL certification (E60677), and CSA certification (File no 007189A), making it a dependable component for electronic and electrical projects.

Features 10 male contacts arranged in a single row for secure connectivity. Offers a pitch of 5.08 mm, compatible with standard PCB designs. Made of durable green polyamide housing for reliable insulation. Supports wire sizes from 30 AWG to 12 AWG, accommodating various wire gauges.

Utilizes a screw wire connection method ensuring strong and stable electrical contact. Designed with a right-angle orientation for convenient PCB mounting and side stacking. Complies with RoHS, UL (E60677), and CSA (File no 007189A) standards for safety and quality.

Maximum wire size supported is 3 mm², and minimum is 0.05 mm². Suitable for use in corrosive environments due to its high-quality materials. Terminal block supplied with open screws to reduce assembly time.

This terminal block is widely used in electronics manufacturing, industrial automation, power distribution, and general electrical equipment assembly. It offers reliable and efficient connectivity solutions, contributing to enhanced system safety and performance. Explore EnvMart for more TE Connectivity products and other advanced electronic components.
