Honeywell Technologies Gauge Pressure Sensor Surface Mount 8 DIP 3.3-5V ±0.25% Accuracy SSCDANV015PGSA3

Free Delivery in India | Lowest Global Shipping Charges

Honeywell Technologies Gauge Pressure Sensor Surface Mount 8 DIP 3.3-5V ±0.25% Accuracy SSCDANV015PGSA3

Name: Honeywell Technologies Gauge Pressure Sensor Surface Mount 8 DIP 3.3-5V ±0.25% Accuracy SSCDANV015PGSA3
Brand: Honeywell
SKU: 168475
Price: 50.53 USD
Availability: InStock



Category Pressure Sensor ICs Brand Honeywell Condition New

Specifications

Country of Origin	India
Accuracy	±0.25 %
Brand	Honeywell
Maximum Operating Pressure	103 kPa
Height	13.75mm
Length	10mm
Model	SSCDANV015PGSA3
Sensor Type	Gauge Pressure Sensor
Mount Type	Surface
Series	SSC
Maximum Operating Temperature	85°C
Port Type	Single Axial Barbed
Package Type	DIP
Minimum Operating Temperature	-40°C
Pin Count	8
Maximum Supply Voltage	5V
Minimum Supply Voltage	3.3V
Minimum Operating Pressure	0psi
Maximum Overload Pressure	207kPa

Key Features

The sensor features a maximum operating pressure of 103 kPa and an overload pressure of 207 kPa.
It utilizes piezoresistive silicon technology for reliable pressure measurement.
The package type is DIP with 8 pins for easy PCB mounting.
It is capable of operating in temperatures from -40°C to 85°C.
The sensor includes a single axial barbed port enabling integration into pressure lines.
This model provides analog or digital output compatible with various applications.
Stable performance with temperature compensation and on-board ASIC calibration.
Compact dimensions of 10 mm length and 13.75 mm height help save PCB space.

Product Description

Honeywell Technologies SSCDANV015PGSA3 is a gauge pressure sensor designed for precise pressure measurement in industrial, electronic, and automotive applications. It features a surface mount package with 8 DIP pins, making it suitable for PCB integration requiring compact and reliable sensing.

This sensor operates within a voltage range of 3.3 to 5 volts and offers industry-leading accuracy of ±0.25% over its full scale pressure range. It supports a maximum operating pressure of 103 kPa and a maximum overload pressure of 207 kPa, ensuring durability under demanding conditions.

The SSCDANV015PGSA3 employs piezoresistive silicon ceramic sensing technology, providing stable and reliable output that is fully calibrated and temperature compensated, minimizing errors from temperature fluctuations. The built-in ASIC updates pressure output values quickly, with sampling rates suitable for both analog and digital signals.

With an operating temperature range from -40°C to 85°C, this sensor suits harsh industrial environments. Its small size, measuring 10 mm in length and 13.75 mm in height, allows installation in compact devices or equipment.

Applications include industrial machinery pressure monitoring, HVAC systems, laboratory equipment, and automotive systems requiring precise pressure sensing. The single axial barbed port enables straightforward connection to pressure lines or chambers.

The sensor has a package DIP type with 8 pins making surface mounting simple. Includes on-board calibration and temperature compensation via ASIC integration. Stable operation even in wide temperature and pressure ranges.

Compact form factor facilitates integration into space-constrained electronics. Enables accurate measurement in a variety of industrial and laboratory pressure sensing tasks. Explore further Pressure Sensor ICs at EnvMart for complementary electronic components from Honeywell and other leading manufacturers.
