Honeywell Technologies Pin Plunger Micro Switch Cable Terminal 100mA 250V AC SPDT IP67 ZW10E90AW1

Honeywell ZW10E90AW1 pin plunger micro switch is a compact mechanical switching device designed for precise control and sensing tasks within industrial automation and electrical systems. Its single-pole double-throw (SPDT) contact configuration and sealed construction accommodate applications requiring reliable actuation under harsh conditions.

The pin plunger actuator provides highly accurate mechanical activation, allowing dependable switching at low currents of 100 mA and voltages up to 250 V AC. The sealed IP67-rated polybutylene terephthalate (PBT) housing ensures resistance to dust, water ingress, and chemical exposure, making it well-suited for demanding environmental conditions. Its ability to operate across a wide temperature span from -40°C up to 120°C supports use in extreme climates and harsh industrial environments.

With a subminiature form factor measuring 19.8 mm in length, 6.4 mm in width, and 9.25 mm in depth, this micro switch fits in tight spaces where precise sensing and switching are critical. The cable terminal connection facilitates straightforward integration into wiring harnesses or control panels. Mechanical durability is excellent with a lifecycle rated at one million operations, helping to reduce maintenance frequency and downtime.

Pin plunger actuator for exact switching performance. 100 mA contact current at 250 V AC capacity. Cable terminal simplifies electrical connections. Polybutylene terephthalate housing offers chemical resistance. IP67 sealing protects against dust and water ingress.

Wide temperature operating range from -40°C to 120°C. Compact subminiature size for space-limited installations. Mechanical life of one million cycles for prolonged service. cUL, UL, RoHS, CQC, and ENEC certifications for safety compliance.

Applications include assembly automation, safety interlocks, position sensing, HVAC status detection, and packaging machinery monitoring.

This Honeywell micro switch is ideal for industries such as manufacturing, HVAC, packaging, and electrical automation where reliable, precise limit switching and safety mechanisms are required. Its robust design and certifications ensure conformity with industrial standards, making it a dependable choice for control and sensing circuits.
