Honeywell Technologies Pin Plunger Micro Switch, Quick Connect Terminal, 16A, 250V AC, SPST, IP40 V19T16-CP100
Specifications
| Country of Origin | China |
|---|---|
| Brand | Honeywell |
| Length | 27.8mm |
| Model | V19T16-CP100 |
| Depth | 15.9mm |
| IP Rating | IP40 |
| Width | 10.3mm |
| Housing Material | Thermoplastic Polybutylene Terephthalate |
| Series | V19 |
| Maximum Operating Temperature | 125°C |
| Contact Configuration | SPST |
| Actuator Type | Pin Plunger |
| Minimum Operating Temperature | -25°C |
| Terminal type | Quick Connect |
| Standards/Approvals | UL, RoHS, ENEC, cUL, CSA, CQC |
| Switch Contact Current | 16A |
| Operating Force | 100g |
| Mechanical Life | 60Cycles |
| Contact AC Voltage | 250V ac |
| Microswitch Type | Unsealed |
Key Features
- Pin plunger actuator type ensures precise mechanical actuation.
- Quick connect terminals allow easy and secure electrical connections.
- Single-pole single-throw (SPST) contact configuration suitable for on/off switching.
- Thermoplastic polybutylene terephthalate housing provides durability and electrical insulation.
- IP40 rated for protection against solid objects larger than 1mm.
- Operating force of 100g enables responsive operation.
- Wide operating temperature range from -25°C to 125°C for versatile applications.
- Unsealed micro switch type designed for indoor use and non-hazardous environments.
Product Description
Honeywell V19T16-CP100 pin plunger micro switch is designed for cost-efficient and reliable switching solutions in industrial and commercial applications. Featuring a quick connect terminal and a single-pole single-throw (SPST) contact configuration rated for 16 amperes at 250 volts AC, this micro switch delivers consistent performance for system auxiliary functions and door latching safety controls.
The housing is made of thermoplastic polybutylene terephthalate, providing excellent durability and electrical insulation, while the IP40 rating offers protection against solid objects larger than 1 mm. The switch operates over a wide temperature range from -25°C to 125°C, making it suitable for diverse environments.
An operating force of 100 grams ensures sensitive and responsive actuation via the pin plunger actuator type. This unsealed micro switch is rated for a mechanical life of 60 million cycles, supporting high-volume, long-term operations.
It complies with various international standards, including UL, RoHS, ENEC, cUL, CSA, and CQC, ensuring safety and regulatory compliance. The micro switch is ideal for use in industrial automation, HVAC systems, control panels, and other electrical applications requiring reliable switching solutions.
Precise pin plunger actuator for reliable operation. Quick connect terminals for easy installation. High current capacity of 16A at 250V AC. Robust thermoplastic housing for electrical insulation. Wide operating temperature from -25°C to 125°C.
IP40 protection for solid object ingress resistance. Unsealed design for indoor industrial environments. Long mechanical life of 60 million cycles. Certified to UL, RoHS, ENEC, cUL, CSA, and CQC standards.
This Honeywell micro switch, model V19T16-CP100, is manufactured in China and is new in condition. It is a trusted solution for industrial automation and electrical control systems. Browse more Micro Switches and electrical components in the Electronics & Electricals category at EnvMart to find compatible products for your applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The Honeywell V19T16-CP100 micro switch has a maximum current rating of 16A.
This micro switch has an IP rating of IP40, providing protection against solid objects larger than 1mm.
It operates over a wide temperature range from -25°C to 125°C.
The switch features a pin plunger actuator type for precise mechanical actuation.
The dimensions are 27.8mm in length, 10.3mm in width, and 15.9mm in depth.
It has a single-pole single-throw (SPST) contact configuration suitable for on/off switching.
The housing is made of thermoplastic polybutylene terephthalate, providing durability and electrical insulation.
The operating force for the micro switch is 100 grams, ensuring responsive operation.
It has a mechanical life rated for 60 million cycles, supporting long-term operations.
This micro switch complies with various standards, including UL, RoHS, ENEC, cUL, CSA, and CQC.
It features quick connect terminals for easy and secure electrical connections.
This model is an unsealed type designed for indoor use and non-hazardous environments.
