Wurth Elektronik WR-MPC3 Series Vertical Surface PCB Header, 14 Contacts, 3 mm Pitch, 2 Row, Shrouded MPC3

Wurth Elektronik MPC3 series vertical surface PCB header, model MPC3, is a high-quality connector designed for surface mount technology applications requiring a wire-to-board system. It features 14 male contacts arranged in two rows with a 3 mm pitch, making it suitable for compact PCB layouts. The header is constructed with a liquid crystal polymer housing that offers excellent thermal stability and mechanical robustness, ensuring durability in demanding environments.

The connector is shrouded in black, providing contact protection and aiding in alignment when mating with connectors or cables. Its copper alloy contacts are plated with tin to enhance conductivity and prevent corrosion over time. Rated to handle 5 amperes of current and withstand voltages up to 250 volts, this PCB header supports a broad range of electronic and electrical applications.

Operating temperatures from -40°C to 105°C allow it to be employed reliably in various industrial, manufacturing, and electronics assembly environments including power supplies, control systems, and telecommunications equipment. The dual-row configuration optimizes space and improves connection density on printed circuit boards.

The header accommodates 14 male contacts arranged in two rows. It uses a 3 mm pitch ensuring compact and precise placement on printed circuit boards. The housing is made of liquid crystal polymer providing durability and thermal resistance.

The connector system is wire-to-board with surface mount technology for secure soldering. Operating temperature ranges from -40°C to 105°C for versatile industrial applications. Rated for 5A current and up to 250V voltage for reliable electrical performance.

Contacts are copper alloy plated with tin for corrosion resistance and conductivity. The black shrouded housing protects contacts and prevents misalignment during mating.

This Wurth Elektronik MPC3 header is ideal for electronics manufacturers and system integrators seeking a robust, reliable, and compact PCB connector solution. It supports a range of industries such as industrial automation, communications, consumer electronics, and instrumentation. Browse the extensive selection of Wurth Elektronik connectors at EnvMart for compatible parts and accessories.
