RS PRO Toggle Switch Panel Mount On-On DPDT SPDT 3A Solder Lug Terminal 209-9356
Specifications
| Country of Origin | China |
|---|---|
| Brand | RS PRO |
| Model | 209-9356 |
| IP Rating | IP67 |
| Mount Type | Panel |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT, SPDT |
| Minimum Operating Temperature | -40°C |
| Terminal type | Solder Lug |
| Standards/Approvals | RoHS 2011/65/EU & 2015/863 |
| Switch Operation | On-On |
| Switch Contact Current | 3A |
| Actuator Material | Chrome Plated Brass |
Key Features
- Panel mount type toggle switch with solder lug terminals.
- Switch operation is On-On allowing two active positions.
- Durable chrome plated brass actuator material ensures long life.
- Rated IP67 waterproof protection for use in harsh environments.
- Suitable for operating temperatures ranging from -40°C to 85°C.
- Compliant with RoHS 2011/65/EU and 2015/863 environmental standards.
- The switch has a mechanical life expectancy of 30,000 make-and-break cycles.
- Applications include telecommunications, industrial controls, and instrumentation.
Product Description
RS PRO 209-9356 toggle switch is a high-quality panel mount On-On toggle switch with DPDT and SPDT contact configurations, rated for a maximum switch contact current of 3A. The switch features a solder lug terminal type and is built with chrome plated brass actuator material for enhanced durability and reliable operation.
This toggle switch complies with IP67 waterproof rating, making it resistant to dust and water ingress. It operates effectively across a wide temperature range from -40°C to 85°C, ensuring reliable performance under extreme conditions. Designed for industrial and telecommunications applications, it offers precise switching functionality with an operating mechanical life of 30,000 make-and-break cycles.
The switch's On-On operation mode provides two active switch states, suitable for controlling electrical circuits with double-pole double-throw or single-pole double-throw functionality. Its compact sub-miniature design allows for easy panel integration with a mounting height of 5.59 mm (thread) and actuator height of 9.40 mm. The switch terminals are silver-plated brass, ensuring excellent conductivity and corrosion resistance.
This product is compliant with RoHS 2011/65/EU and 2015/863, meeting environmental standards for hazardous substances. Its robust construction and compact size make it highly suitable for use in a variety of industrial controls including joysticks, grips, power supplies, elevator controls, marine panels, medical food processing equipment, wheelchairs, security systems, and test and measurement devices.
Panel mount Toggle Switch with On-On operation and solder lug terminals. Rated for 3A contact current with DPDT and SPDT configurations. Chrome plated brass actuator material and silver-plated contacts. IP67 dust and waterproof rating for harsh environment durability.
Operating temperature range from -40°C to 85°C with 30,000 mechanical cycles life. Compliant with RoHS environmental directives ensuring lead-free construction. Ideal for telecommunications, industrial automation, instrumentation, and control panels.
Compact sub-miniature design enabling space-saving panel installation. Suitable for use in elevators, medical, marine, security, and measurement applications. Explore the comprehensive RS PRO range on EnvMart to find compatible electrical components and switches tailored for your industrial and commercial needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The toggle switch has an IP67 rating, making it resistant to dust and water ingress, suitable for harsh environments.
It is rated for a maximum switch contact current of 3A.
This model features DPDT (Double Pole Double Throw) and SPDT (Single Pole Double Throw) contact configurations.
The operating temperature range is from -40°C to 85°C, allowing it to function effectively in extreme conditions.
It features solder lug terminals, which are designed for secure connections.
The switch has a mechanical life expectancy of 30,000 make-and-break cycles.
The actuator is made from chrome plated brass, which enhances its durability and reliability.
Yes, it is compliant with RoHS 2011/65/EU and 2015/863 environmental standards.
It is suitable for applications in telecommunications, industrial controls, instrumentation, and various control panels.
This model is designed for panel mounting, allowing for easy integration into control panels.
The actuator height is 9.40 mm, allowing for compact installation in panel setups.
The country of origin for this toggle switch is China.
