Samtec Vertical Surface Pin Header 36 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-118-01-T-DV

Free Delivery in India | Lowest Global Shipping Charges

Samtec Vertical Surface Pin Header 36 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-118-01-T-DV

Name: Samtec Vertical Surface Pin Header 36 Contacts 2.54 mm Pitch 2 Row Unshrouded TSM-118-01-T-DV
Brand: Samtec
SKU: 167158
Price: 3.02 USD
Availability: InStock



Category PCB Headers Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	475V
Brand	Samtec
Orientation	Vertical
Model	TSM-118-01-T-DV
Mount Type	Surface
Housing Material	Liquid Crystal Polymer
Contact Material	Phosphor Bronze
Series	TSM
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	2
Pitch	2.54mm
Contact Plating	Gold or Tin
Number of Contacts	36
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board

Key Features

Constructed with a liquid crystal polymer housing for durability.
Contact material is high-quality phosphor bronze with gold or tin plating for optimal conductivity.
Designed for surface mount with vertical orientation and male contact gender.
Operates within -55°C to 125°C temperature range ensuring versatility in applications.
Rated for 475V operating voltage suitable for board-to-board connector systems.
Termination type is solder-compatible for reliable PCB mounting.
Unshrouded design allows easy access and soldering on PCB assemblies.
Two rows with 2.54 mm row pitch provide reliable multi-contact connections.

Product Description

Samtec TSM-118-01-T-DV vertical surface pin header is a high-quality electronic component designed for board-to-board connections. It features 36 male contacts arranged in two rows with a 2.54 mm pitch. The header's housing is manufactured using liquid crystal polymer, offering mechanical strength and heat resistance suitable for various industrial electronics applications.

The contacts are made of phosphor bronze and plated with gold or tin to provide excellent conductivity and corrosion resistance. It is an unshrouded vertical header designed for surface mounting on PCBs, with termination suited for solder processes. It supports an operating temperature range from -55°C up to 125°C and has a maximum voltage rating of 475V, enabling use in demanding environments.

This connector type is commonly used in electronic manufacturing, industrial automation, and telecommunications, where reliable board interconnections are critical. The precision pitch and dual-row configuration facilitate dense PCB layouts without sacrificing reliability.

The solder termination and unshrouded design allow ease of access during assembly and maintenance. This product complies with general electronic component standards but does not carry specific certifications mentioned.

Constructed with liquid crystal polymer housing for durability. Phosphor bronze contacts with gold or tin plating ensure high conductivity. 36 contact points arranged in two rows with 2.54 mm pitch. Designed for surface mount with vertical orientation and male gender connectors.

Wide operating temperature -55°C to 125°C suitable for harsh environments. Voltage rating at 475V for reliable electrical performance. Solder termination type compatible with standard PCB assembly processes. Unshrouded design facilitates accessible soldering and inspection.

Ideal for industrial, electronic manufacturing, telecom, and automated assembly applications. Explore other PCB header and electronic connector products to complete your project requirements on EnvMart.
