Samtec TSM Series Vertical Surface Pin Header, 20 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded TSM-110-02-T-SV

The Samtec TSM-110-02-T-SV Vertical Surface Pin Header is a high-quality electronic connector designed for reliable board-to-board interfacing in industrial and electronic applications. It features a single row of 20 male contacts with a standard 2.54 mm pitch and unshrouded design to facilitate easy solder mounting.

The header’s housing is crafted from black liquid crystal polymer, providing robust insulation and stability under demanding conditions. Contacts are made from phosphor bronze for excellent mechanical strength and conductivity, plated with gold or tin for enhanced corrosion resistance.

This pin header operates efficiently across a wide temperature range from -55°C up to 125°C, making it suitable for environments with varying thermal stress. It supports a maximum operating voltage of 475 VAC, ensuring compatibility with typical industrial power requirements.

The vertical orientation allows for streamlined PCB assembly and integration in electronic devices. With its surface-mount design, it secures firmly to printed circuit boards through soldered connections, supporting high-volume manufacturing processes.

Typical applications for the TSM series pin header include industrial control systems, telecommunications equipment, computing devices, and other electronic assemblies requiring durable, high-performance connectors.

The pin header features a durable liquid crystal polymer housing ensuring insulation and stability. Manufactured with phosphor bronze contacts plated in gold or tin for reliable conductivity. Supports solder termination for secure mounting on PCB surfaces.

Operates within a temperature range from -55°C to 125°C suitable for various industrial applications. Designed for vertical orientation with a standard 2.54 mm row pitch for easy integration. Rated for voltage up to 475 V AC, suitable for electronic component interconnection.

Ideal for use in electronics manufacturing, communications, and industrial automation. Explore more connectors and electronic components in the EnvMart categories for PCB Headers and Electronics Components to find compatible parts for your projects.
