Samtec Pin Header Through Hole 23 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-123-07-G-S

Free Delivery in India | Lowest Global Shipping Charges

Samtec Pin Header Through Hole 23 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-123-07-G-S

Name: Samtec Pin Header Through Hole 23 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-123-07-G-S
Brand: Samtec
SKU: 167069
Price: 3.13 USD
Availability: InStock



Category PCB Pin Header Brand Samtec Condition New

Specifications

Country of Origin	India
Voltage	550V
Brand	Samtec
Orientation	Straight
Model	TSW-123-07-G-S
Mount Type	Through Hole
Special Features	Many options fo
Housing Material	Glass Filled Polyester
Contact Material	Phosphor Bronze
Series	TSW
Termination	Through-hole
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	23
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Board-to-Board
Contact System	.025" (0.635 mm) square post

Key Features

The header features glass filled polyester housing for durability and stability.
Contact material is phosphor bronze with gold plating ensuring excellent conductivity and corrosion resistance.
Operates reliably between -55°C to 125°C temperature range.
Designed for through-hole mounting with a vertical, straight orientation.
Suitable for applications needing up to 550V operating voltage.
Termination type is solder compatible for secure electrical connections.
The contact system uses a 0.025" (0.635 mm) square post for robust mechanical connection.

Product Description

Samtec TSW-123-07-G-S Pin Header is a precision-engineered electronic component featuring 23 contacts arranged in a single row with a 2.54 mm (0.1 inch) pitch. The product is designed for through-hole mount applications and offers a reliable solution for board-to-board connections in various electronic devices.

The housing is made from robust glass filled polyester, providing excellent mechanical strength and electrical insulation. The pins are manufactured from phosphor bronze and plated with gold to ensure superior conductivity and resistance to corrosion, vital for maintaining signal integrity over time.

This pin header supports operating temperatures ranging from -55°C up to 125°C, making it suitable for harsh industrial environments. It sustains a maximum operating voltage of 550V, covering a variety of electronic design requirements.

Its straight orientation and unshrouded design facilitate easy soldering and integration on printed circuit boards. The termination method is solder-based, affording a secure and durable mechanical and electrical connection.

Applications of this pin header span numerous industrial sectors including manufacturing, telecommunications, consumer electronics, and instrumentation, where dependable electrical connections are paramount. Its specifications support usage in both commercial and industrial environments needing dependable and compact connector solutions.

The pin header's design ensures compatibility with standard PCB layouts measuring a precise 2.54 mm pitch. Its single row and 23 contact configuration suit applications requiring moderate pin counts and density. Gold-plated phosphor bronze contacts reduce wear and improve lifespan in repetitive mating cycles.

Widely used in electronic component assembly lines and prototyping setups due to its standard dimensions. Efficient through-hole mounting ensures mechanical stability and reliable electrical contact in assembled circuits.

This product is categorized under PCB Pin Header within Electronics Components, facilitating easy sourcing in related industrial and electronic material inventories on EnvMart.
