Samtec TSW Series Straight Through Hole Pin Header 26 Contacts 2.54 mm Pitch 2 Row Unshrouded TSW-113-08-F-D-RA
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-113-08-F-D-RA |
| Mount Type | Through Hole |
| Special Features | Many options fo |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 26 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- The connector is unshrouded and has a straight orientation for versatile applications.
- Contact material is phosphor bronze with gold plating, enhancing conductivity and corrosion resistance.
- Housing is made from glass filled polyester providing durability and electrical insulation.
- This through-hole mounted header supports a voltage rating up to 550V.
- Operates reliably between temperatures of -55°C to 125°C.
- Contact gender is male with square post contacts sized at 0.025 inches (0.635 mm).
- Termination type is solder through-hole for secure PCB connections.
- The product is suitable for industrial and electronic manufacturing applications requiring reliable board-to-board connectors.
Product Description
Samtec TSW-113-08-F-D-RA is a high-quality straight through hole pin header designed for board-to-board electronic connectivity, featuring 26 contacts in 2 rows with a 2.54 mm pitch. Constructed with a glass filled polyester housing and phosphor bronze contacts plated with gold, it ensures durability, excellent electrical performance, and corrosion resistance under demanding industrial conditions.
The pin header mounting is through-hole with a solder termination type, which guarantees stable mechanical and electrical connection on printed circuit boards. It operates within a wide temperature range from -55°C to 125°C, making it suitable for diverse environments including industrial electronics, manufacturing equipment, and control systems.
Operating voltage rating is 550V, supporting applications requiring moderate voltage handling. The 0.025 inch (0.635 mm) square post contact system along with a male contact gender accommodates standard mating connectors. This product is unshrouded, allowing easier inspection and soldering while maintaining robust connectivity.
The connector features two rows of 26 contacts ensuring adequate pin density. Gold plating on phosphor bronze contacts provides reliable conductivity and prevents oxidation. Glass filled polyester housing offers mechanical strength and electrical insulation.
Through-hole mounting and solder termination enable secure installation on PCBs. Wide operating temperature range (-55 to 125°C) supports harsh industrial environments. Voltage rating up to 550V allows use in various electronic applications.
Unshrouded design facilitates access and compatibility with different connector types. Robust construction makes it suitable for industrial, manufacturing, and electronic equipment.
This Samtec TSW Series pin header is ideal for engineering professionals designing board-to-board connectivity solutions. Its durable materials and reliable performance ensure long-lasting and maintenance-free operation in industrial, commercial, and laboratory settings.
