Texas Instruments Digital to Analogue Converter 12 Bit Serial-I2C Interface 8-Pin MSOP DAC121C085CIMM/NOPB
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 12 bit |
| Brand | Texas Instruments |
| Height | 3mm |
| Model | DAC121C085CIMM/NOPB |
| Width | 0.86mm |
| Mount Type | Surface |
| Settling Time | 8.5μs |
| Series | DAC121C085 |
| Maximum Operating Temperature | 125°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Interface Type | Serial-I2C |
| Architecture | Resistor String |
| Standards/Approvals | RoHS, REACH |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3.3V |
Key Features
- Offers a single channel with resistor string architecture for precise DAC output.
- Compact 8-pin MSOP package suitable for surface mount applications.
- Operates within a supply voltage range of 3.3V to 5.5V.
- Features a fast settling time of 8.5 microseconds for quick signal response.
- Functions reliably across a wide temperature range from -40°C to 125°C.
- Utilizes external voltage reference for high accuracy output.
- Compliant with RoHS and REACH environmental standards.
- Ideal for industrial, laboratory, and embedded system applications requiring digital to analogue conversion.
Product Description
The Texas Instruments DAC121C085CIMM/NOPB is a high-performance digital to analogue converter featuring 12 bit resolution and utilizing a resistor string architecture to deliver accurate voltage output. This model comes in a compact 8-pin MSOP surface mount package, facilitating easy integration into a wide range of electronic circuit boards.
Designed for efficient interfacing, it employs a Serial-I2C communication protocol, making it suitable for low-pin count, high-speed applications. The device operates across a supply voltage range from 3.3V to 5.5V, ensuring compatibility with various power systems.
With a settling time of just 8.5 microseconds, this DAC121C085CIMM/NOPB model allows for rapid signal transitions, beneficial in control systems and signal processing applications. It supports operation in extreme temperature environments from -40°C to 125°C, making it reliable for harsh industrial and automotive conditions, although automotive standard compliance is not specified.
The external voltage reference input allows for enhanced accuracy and flexibility in analog output signals. This product adheres to RoHS and REACH standards, reflecting its environmental compliance and suitability for global market requirements.
Typical applications include industrial automation, laboratory instrumentation, embedded systems, and control electronics requiring precise voltage adjustments. Its small form factor coupled with robust specifications makes it an excellent choice for designers seeking reliable DAC solutions.
Single channel 12 bit DAC with resistor string architecture. Surface mount 8-pin MSOP package for compact design integration. Wide operating voltage range from 3.3V to 5.5V. Fast 8.5 microsecond settling time suitable for high-speed applications.
Supports industrial temperature range from -40°C to 125°C. External voltage reference input for increased accuracy. RoHS and REACH compliant for environmental safety. Applications in industrial, laboratory, and embedded system electronics.
Explore more Digital to Analogue Converter options and Texas Instruments products at EnvMart for comprehensive industrial and electronic component needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model features a resolution of 12 bits, allowing for precise digital to analogue conversion.
It operates within a supply voltage range of 3.3V to 5.5V, making it compatible with various power systems.
The settling time for this model is 8.5 microseconds, suitable for high-speed applications requiring quick signal response.
It employs a Serial-I2C communication protocol, facilitating efficient interfacing in low-pin count applications.
This unit functions reliably across a wide temperature range from -40°C to 125°C, suitable for harsh environments.
It is housed in a compact 8-pin MSOP surface mount package, ideal for integration into electronic circuit boards.
This model features a single channel, providing a straightforward solution for digital to analogue conversion needs.
It utilizes a resistor string architecture, which contributes to its accurate voltage output capabilities.
Yes, it is compliant with RoHS and REACH environmental standards, reflecting its suitability for global market requirements.
The dimensions of this model are 3mm in height and 0.86mm in width, making it compact for various applications.
Typical applications include industrial automation, laboratory instrumentation, and embedded systems requiring precise voltage adjustments.
The country of origin for this model is India, reflecting its manufacturing location.
