Texas Instruments 16-Bit Resistor String DAC with Microwire, SPI, QSPI Interface, 93 ksps Sampling Rate, 8-Pin DAC8501E/250
Specifications
| Country of Origin | India |
|---|---|
| Resolution | 16 bit |
| Brand | Texas Instruments |
| Height | 1.1mm |
| Length | 3.1mm |
| Model | DAC8501E/250 |
| Width | 3.1mm |
| Mount Type | Surface |
| Settling Time | 10μs |
| Sampling rate | 93ksps |
| Output type | Analogue Voltage |
| Maximum Operating Temperature | 105°C |
| Package Type | MSOP |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Interface Type | Microwire, SPI, QSPI |
| Architecture | Resistor String |
| Pin Count | 8 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3.3V |
Key Features
- The DAC architecture is based on a resistor string for precise voltage output.
- Single channel device suitable for general and specialized audio applications.
- Supports multiple serial interfaces including Microwire, SPI, and QSPI for flexible connectivity.
- Operates with a supply voltage range from 3.3V minimum up to 5.5V maximum.
- Compact dimensions measuring 3.1 mm length, 3.1 mm width, and 1.1 mm height in an MSOP surface mount package.
- Wide operating temperature range from -40°C to 105°C ensures reliability in industrial environments.
- Fast settling time of 10 microseconds for quick signal response.
- External voltage reference input for precise output voltage control.
Product Description
Texas Instruments DAC8501E/250 is a 16-bit digital-to-analogue converter employing a resistor string architecture, designed to deliver high accuracy analogue voltage output for various industrial, laboratory, and audio applications.
This DAC features flexible serial interface options including Microwire, SPI, and QSPI, allowing seamless integration with diverse microcontrollers and digital systems. With a sampling rate of 93 ksps, it supports moderate-speed signal conversion requirements.
Designed for surface mount applications, the 8-pin MSOP package measures just 3.1 mm by 3.1 mm by 1.1 mm, making it suitable for compact PCB designs. The device operates reliably over a wide temperature range from -40°C to +105°C, suitable for harsh industrial conditions.
The DAC supports a supply voltage range from 3.3V to 5.5V and includes an external voltage reference input to allow precise tuning of output voltage levels. Its fast 10 microsecond settling time ensures prompt analogue response after digital input changes, important for dynamic signal processing.
The DAC8501E/250 is ideal for use in industrial automation, instrumentation, signal processing, audio engineering, and embedded systems applications. Its small form factor and multiple interface options provide design flexibility for engineers developing compact and efficient devices.
Surface mount package eases automated assembly and high-volume manufacturing. Accurate analogue voltage outputs are achieved through the resistor string architecture. Robust operating temperature and voltage range extend applicability in demanding operational environments.
Explore Texas Instruments and other semiconductor components in the Digital to Analogue Converter category at EnvMart for high quality, reliable products to meet your precision electronics needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The DAC8501E/250 has a resolution of 16 bits, allowing for precise analogue voltage output.
The maximum supply voltage for the DAC8501E/250 is 5.5V.
It supports multiple serial interfaces including Microwire, SPI, and QSPI for flexible connectivity.
This model measures 3.1 mm in length, 3.1 mm in width, and 1.1 mm in height, designed for surface mount applications.
The DAC8501E/250 operates reliably over a wide temperature range from -40°C to 105°C.
The settling time for this device is 10 microseconds, ensuring quick signal response.
This model features a single channel, making it suitable for various applications.
The architecture of this DAC is based on a resistor string, which contributes to its accurate voltage output.
The minimum supply voltage required for the DAC8501E/250 is 3.3V.
The DAC8501E/250 is manufactured in India.
