Samtec TSW Series Straight Through Hole Pin Header 6 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-106-15-F-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-106-15-F-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- Constructed with glass filled polyester housing for enhanced durability.
- Phosphor bronze male contacts with gold plating ensure excellent conductivity and corrosion resistance.
- Designed for through hole mounting with a straight orientation for secure PCB fit.
- Supports a voltage rating up to 550V suitable for various electronic applications.
- Operates reliably across a wide temperature range from -55°C to 125°C with gold plating.
- Unshrouded design allows easy access and solder termination.
- Compliant with RoHS standards, ensuring environmental safety.
- Ideal for industrial, manufacturing, and electronic system assembly use cases.
Product Description
Samtec TSW-106-15-F-S is a high-quality straight through hole pin header designed for reliable board-to-board connections. Featuring a single row of 6 contacts with a standard 2.54 mm pitch, this unshrouded header is made with a housing material of black glass filled polyester, providing excellent mechanical robustness and thermal stability.
The male phosphor bronze contacts are plated with gold to guarantee excellent electrical performance and corrosion resistance in demanding environments. Suitable for through hole mounting and solder termination, this pin header supports a voltage rating of up to 550V, making it suitable for a broad range of commercial, industrial, and manufacturing electronic applications.
It operates safely in temperature ranges between -55°C and +125°C when gold plating is used, ensuring durability even under severe thermal conditions.
Its unshrouded construction facilitates straightforward installation and maintenance, providing versatility in electronic system design. The TSW series is RoHS compliant, aligning with environmental regulations for safer products.
Constructed with robust glass filled polyester housing for mechanical and thermal endurance. Gold-plated phosphor bronze male contacts for high conductivity and corrosion resistance. Standard 2.54 mm pitch with 6 contacts in a single row for compact PCB designs.
Through hole mount type with straight orientation for easy installation. Voltage rating up to 550V, supporting multiple industrial and manufacturing applications. Wide operating temperature range from -55°C to +125°C with gold plating.
Unshrouded style enabling easy soldering and maintenance. RoHS compliant, ensuring adherence to environmental standards.
This pin header is suitable for use in industrial controls, electronic manufacturing, automation systems, and instrumentation electronics. It offers reliable electrical connections in various laboratory, manufacturing, commercial, and construction environments.
Explore more high-quality PCB Headers and electronic components from trusted brands in our Electronics Components catalog at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a voltage rating of up to 550V, making it suitable for various electronic applications.
The TSW-106-15-F-S features a standard pitch of 2.54 mm, which is common for PCB connections.
It is constructed with a glass filled polyester housing and features phosphor bronze male contacts plated with gold for enhanced conductivity and corrosion resistance.
The pin header operates reliably across a wide temperature range from -55°C to +125°C when gold plating is used.
This pin header has a total of 6 contacts arranged in a single row.
It utilizes solder termination, which is suitable for through hole mounting applications.
Yes, this model is RoHS compliant, ensuring it meets environmental safety regulations.
The TSW-106-15-F-S features a straight orientation for easy installation on PCBs.
This model has male contacts, which are designed for board-to-board connections.
The maximum operating temperature for the TSW-106-15-F-S is 125°C when using gold plating.
This pin header is manufactured in India.
It supports through hole mounting, which allows for secure placement on printed circuit boards.
