Samtec TSW Series 2 Contact 2.54 mm Pitch 2 Row Unshrouded Straight Through Hole Pin Header TSW-101-08-G-D
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-101-08-G-D |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 2 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Operating temp range | -55 °C to +125 °C with Gold -55 °C to +105 °C with Tin |
| Plating used | Au or Sn over 50 μ" (1.27 μm) Ni |
Key Features
- Constructed with glass filled polyester housing for durability.
- Male phosphor bronze contacts plated with gold for reliable conductivity.
- Designed for through hole mounting in board-to-board connector systems.
- Operates within a temperature range of -55°C to +125°C.
- Contact termination is via solder, providing secure connections.
- Unshrouded design facilitates ease of access in assemblies.
- Suitable for electronic components and PCB header applications.
Product Description
Samtec TSW-101-08-G-D is a part of the TSW Series straight through hole pin headers, offering a high-quality electrical connection solution for PCB assemblies. Its housing is made from black glass filled polyester providing excellent insulation and mechanical strength.
The contact pins are made from phosphor bronze and plated with gold (Au) ensuring both conductivity and resistance to corrosion. The connector is designed for through hole mounting and serves in board-to-board connector systems, suitable for various industrial and electronic equipment.
It operates reliably across a wide temperature range from -55°C to +125°C, making it suitable for harsh environments. Voltage rating is specified up to 550V allowing safe operation within typical electronic circuitry requirements. The termination method is solder, offering secure and stable electrical connections.
The product is unshrouded, providing direct access to the contacts which facilitates easy assembly or repair in electronic manufacturing processes. This pin header is widely applicable in electronics, industrial automation, telecommunication, and related sectors requiring reliable PCB connectors.
Constructed with glass filled polyester housing for durability. Male phosphor bronze contacts plated with gold for reliable conductivity. Designed for through hole mounting in board-to-board connector systems. Operates within a temperature range of -55°C to +125°C.
Voltage rating up to 550V ensures safety in electrical applications. Contact termination is via solder, providing secure connections. Unshrouded design facilitates ease of access in assemblies. Suitable for electronic components and PCB header applications.
This Samtec TSW Series pin header is RoHS compliant, supporting eco-friendly manufacturing. It is trusted in industrial, electronic manufacturing, telecommunications, and other commercial applications that require robust and precise PCB connectors.
Explore more PCB Pin Headers and electronic connectors on EnvMart for optimal quality and industrial-grade performance solutions.
