Samtec TMS Series Straight Through Hole Pin Header, 20 Contacts, 1.27 mm Pitch, 1 Row, Unshrouded, Gold TMS-120-02-G-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 281V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 5A |
| Model | TMS-120-02-G-S |
| Mount Type | Through Hole |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Current Rating | 5A per pin (2 pins powered) |
| Series | TMS |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 20 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
Key Features
- Constructed with phosphor bronze contacts and gold plating for enhanced conductivity and corrosion resistance.
- Designed as a through-hole board-to-board connector system for reliable straight orientation mounting.
- Supports a current rating of 5A per pin with two pins powered for optimal electrical capacity.
- Operates within a temperature range from -55°C to 125°C for versatility in demanding environments.
- Features housing made of durable black liquid crystal polymer ensuring mechanical stability and resistance.
- Unshrouded design facilitates easy solder type termination and inspection.
- Rated for voltage up to 281V suitable for industrial and electronic assembly applications.
- Ideal for printed circuit board (PCB) connector solutions in electronic, industrial, and power applications.
Product Description
Samtec TMS-120-02-G-S is a high-quality Through Hole Pin Header from the TMS series designed for electronic equipment assembly requiring dependable board-to-board connections.
This 20 contact, 1.27 mm pitch, 1-row header is unshrouded, providing easy access for soldering and inspection. The contacts are made from phosphor bronze, plated with gold to ensure excellent electrical conductivity and corrosion resistance, critical for long-term reliability.
The housing is constructed from black liquid crystal polymer, delivering superior mechanical strength and thermal stability, supporting operation in severe temperature ranges from -55°C up to 125°C.
This connector supports a 5A current capacity per pin with two pins powered concurrently and can handle voltages up to 281V, making it suitable for a wide range of commercial, industrial, and laboratory electronic applications.
Its straight orientation and through-hole mounting type allow for stable mechanical and electrical connections on PCBs. The unshrouded design enables flexible integration into various circuits while maintaining ease of access.
Common use cases include electronic device manufacturing, power electronics, industrial automation, telecommunications, and instrumentation where reliable, high-quality PCB connectors are essential.
Constructed with phosphor bronze contacts and gold plating for superior conductivity. Liquid crystal polymer housing provides robust mechanical and thermal performance. Rated for 5A current per pin and 281V voltage capacity.
Suitable for through-hole mounting in board-to-board connector systems. Works effectively in temperature ranges from -55°C to 125°C. Unshrouded, single-row design with 20 contacts at 1.27 mm pitch. Widely applicable in industrial, electronic, and commercial PCB assemblies.
Explore more PCB connectors and related components in the Electronics Components category on EnvMart for your industrial and manufacturing needs.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a current rating of 5A per pin, with the capability to power two pins concurrently for optimal electrical capacity.
The connector is rated for a maximum voltage of 281V, making it suitable for various industrial and electronic applications.
It operates effectively within a temperature range of -55°C to 125°C, allowing for versatility in demanding environments.
The contacts are made from phosphor bronze and are plated with gold for enhanced conductivity and corrosion resistance, while the housing is constructed from liquid crystal polymer.
This pin header features 20 contacts, arranged in a single row with a pitch of 1.27 mm.
It utilizes a solder termination type, which facilitates easy soldering and inspection during assembly.
The TMS-120-02-G-S has a straight orientation, designed for stable mechanical and electrical connections on PCBs.
This unit is designed for through-hole mounting, allowing for reliable board-to-board connections.
It features an unshrouded design, which provides easy access for soldering and inspection.
It is suitable for various applications including electronic device manufacturing, power electronics, industrial automation, telecommunications, and instrumentation.
The contacts in this model are male, designed for connection with female counterparts in PCB assemblies.
The country of origin for this pin header is India.
