Samtec TMS Series Straight Through Hole Pin Header, 10 Contact(s), 1.27 mm Pitch, 1 Row, Unshrouded TMS-110-01-G-S

Samtec TMS-110-01-G-S is a high-quality, straight through hole pin header from the TMS Series, featuring 10 contacts with a 1.27 mm pitch and single-row unshrouded design. This pin header is engineered to provide reliable electrical connections for board-to-board applications.

The connector is constructed with phosphor bronze contacts plated with gold to ensure excellent conductivity and corrosion resistance. The housing is made from liquid crystal polymer, which offers superior durability and can withstand operating temperatures ranging from -40°C up to 125°C.

This pin header utilizes a through-hole solder termination type and a straight orientation, making it well-suited for secure mounting on printed circuit boards. The contact system features a .018" (0.46 mm) square post design with a 3.05 mm tail pin length and a mating pin length of 5.84 mm, optimizing mechanical stability and electrical performance.

Its unshrouded board-to-board connector system allows for straightforward assembly and maintenance in industrial electronics, manufacturing, and other commercial electronic applications.

Offers a current rating of 5A ensuring efficient power handling. Features phosphor bronze contacts plated with gold for enhanced conductivity. Constructed with liquid crystal polymer housing for durability and heat resistance.

Designed for through-hole mounting with solder termination for secure attachment. Operates within a temperature range from -40°C to 125°C for versatile applications. Includes 3.05 mm tail pin length and 5.84 mm mating pin length for secure mating.

Utilizes a straight orientation with unshrouded connector style for easy access. Suitable for board-to-board connector systems in electronic devices. Standard 1.27 mm row pitch and .018" (0.46 mm) square post contact system enhances compatibility.

Ideal for use in industrial electronics and PCB assembly environments.
