Samtec TSW Series Straight Through Hole Pin Header 50 Contacts 2.54 mm Pitch 1 Row Unshrouded TSW-150-06-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Model | TSW-150-06-T-S |
| Mount Type | Through Hole |
| Housing Material | Glass Filled Polyester |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 50 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with glass filled polyester housing for durability.
- Phosphor bronze contacts plated with gold ensure reliable conductivity.
- Operates within a temperature range from -55°C to 125°C.
- Designed for solder termination with male contact gender.
- Supports voltage rating up to 550V for robust applications.
- Single row, straight orientation for standard PCB mounting.
- Features a .025" (0.635 mm) square post contact system for secure connection.
- Industry-grade through-hole mount for mechanical stability.
Product Description
Samtec TSW-150-06-T-S is a high-quality through-hole pin header designed for electronic board-to-board connections. Featuring a single row of 50 male contacts, this pin header uses a 2.54 mm pitch, making it compatible with a wide range of PCB layouts in industrial and commercial electronics.
The housing is crafted from glass filled polyester, providing mechanical strength and environmental resistance. Contacts are made from phosphor bronze and plated with gold, ensuring excellent electrical performance and resistance to corrosion over many mating cycles.
This connector operates reliably in a broad temperature range from -55°C up to 125°C, suitable for demanding operating conditions. The unshrouded, straight orientation design facilitates easy soldering and integration on printed circuit boards using through-hole mounting techniques.
Voltage rating of 550V allows use in various power and signal applications where durability and safety are critical. The .025" (0.635 mm) square post contact system enhances the mechanical retention and electrical contact reliability.
Constructed with glass filled polyester housing for durability. Phosphor bronze contacts plated with gold ensure reliable conductivity. Operates within a temperature range from -55°C to 125°C. Designed for solder termination with male contact gender.
Supports voltage rating up to 550V for robust applications. Single row, straight orientation for standard PCB mounting. Features a .025" (0.635 mm) square post contact system for secure connection. Industry-grade through-hole mount for mechanical stability.
This Samtec TSW series product is ideal for electronic component assembly in industrial manufacturing, telecommunications, automotive electronics, instrumentation, and commercial device production. It is engineered to meet stringent quality and operational standards for reliable long-term service.
Explore the Electronics Components category on EnvMart for compatible connectors and complementary PCB accessories.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model supports a voltage rating of up to 550V, making it suitable for various power and signal applications.
It operates reliably within a temperature range from -55°C to 125°C, accommodating demanding environmental conditions.
This unit features 50 male contacts arranged in a single row, designed for effective board-to-board connections.
The contact pitch for this pin header is 2.54 mm, which is compatible with a wide range of PCB layouts.
The housing is made of glass filled polyester, while the contacts are phosphor bronze plated with gold for enhanced conductivity and corrosion resistance.
It is designed for solder termination, allowing for secure mounting on printed circuit boards.
This model has a straight orientation, which facilitates easy integration into PCB layouts.
It is an unshrouded pin header, allowing for straightforward soldering and connection.
It features a .025" (0.635 mm) square post contact system, which enhances mechanical retention and electrical contact reliability.
This model supports through-hole mounting, providing mechanical stability in electronic assemblies.
The country of origin for this pin header is India, indicating its manufacturing location.
It is ideal for electronic component assembly in industrial manufacturing, telecommunications, automotive electronics, and instrumentation.
