MEAN WELL SD-100 Series Surface Mount DC/DC Converter 12V Output, 19-36V Input, 102W, 75% Efficiency, -10°C to SD-100B-12
Specifications
| Country of Origin | China |
|---|---|
| Voltage | Converters / DC-DC Converters MEAN WELL SD-100 DC/DC Converter, 12V dc/ 0 A, 36V |
| Brand | MEAN WELL |
| Efficiency | 75% |
| Length | 199mm |
| Model | SD-100B-12 |
| Depth | 38mm |
| Gross Weight | 650g |
| Width | 98mm |
| Mount Type | Surface |
| Series | SD-100 |
| Maximum Operating Temperature | 60°C |
| Minimum Operating Temperature | -10°C |
| MTBF | 2600200h |
| Number of outputs | 1 |
| Ripple and Noise | 120mV Pk-Pk |
| Maximum Output Power | 102W |
| Maximum Input Voltage | 36V dc |
| Standards/Approvals | EN/IEC |
| Minimum Input Voltage | 19V |
| Output Voltage 1 | 12V dc |
| Output Current 1 | 0A |
| Output Voltage Adjustment Range | 16 V |
| Isolation Voltage | 1.5kV ac |
| Output Current 2 | 8.5A |
| Input Ratio | 2:1 |
| Input Ratio 2 | 1 |
| Wide 2 | 1 input voltage range |
Key Features
- Wide input voltage range from 19V to 36V ensures versatile application.
- High efficiency of 75% reduces power loss and heat generation.
- Compact surface mount design with dimensions 199mm x 98mm x 38mm.
- Operating temperature range from -10°C to 60°C for reliable performance.
- Provides reliable isolation with 1.5kV AC isolation voltage.
- Equipped with LED power-on indicator for easy status monitoring.
- Short circuit, overload, and overvoltage protections enhance durability.
- Adjustable output voltage within 16V range for customized applications.
Product Description
MEAN WELL SD-100B-12 is a high-reliability DC/DC converter belonging to the SD-100 series, designed for industrial and electronic applications requiring stable 12V output at 102W maximum power. It supports a wide input voltage range from 19V to 36V DC and integrates into devices via surface mount installation. The converter operates efficiently at 75%, ensuring minimal energy loss and prolonged device life.
This converter features an adjustable output voltage range up to 16V and includes protective mechanisms against short circuits, overloads, and overvoltage, providing safe and reliable operation in harsh environments. An LED indicator facilitates easy monitoring of power status.
Its compact form factor with a length of 199mm, width of 98mm, and depth of 38mm makes it suitable for space-constrained setups. The unit is rated for operation between -10°C and 60°C, with a robust isolation voltage of 1.5kV AC ensuring electrical safety between input and output circuits.
The Mean Time Between Failures (MTBF) rating of 2,600,200 hours demonstrates the product's durability and reliability, ideal for demanding industrial and commercial electronics uses including power supplies, communication equipment, and control systems.
Wide 2:1 input voltage range from 19V to 36V DC. Surface mount design with screw terminals enables easy installation. Overvoltage, overload, and short circuit protections improve system safety. LED power-on indicator for clear visual status.
MTBF to MIL-HDBK-217F shows high reliability for industrial applications.
Designed and manufactured with compliance to EN/IEC standards, this DC/DC converter is a robust solution for power conversion needs in electronics manufacturing, laboratory, industrial automation, and power management systems. Explore more DC/DC Converter options with MEAN WELL at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The input voltage range for the MEAN WELL SD-100B-12 is from 19V to 36V DC.
This model provides a maximum output power of 102W.
The efficiency rating of the SD-100B-12 is 75%.
The dimensions of the SD-100B-12 are 199mm in length, 98mm in width, and 38mm in depth.
This unit operates within a temperature range of -10°C to 60°C.
Yes, it includes protections against short circuits, overloads, and overvoltage.
The adjustable output voltage range is up to 16V.
This model supports surface mount installation.
The isolation voltage of this converter is 1.5kV AC.
The ripple and noise specification is 120mV peak-to-peak.
The MTBF for the SD-100B-12 is rated at 2,600,200 hours.
This converter is designed and manufactured in compliance with EN/IEC standards.
