Buschjost 2 Port Normally Closed Solenoid Valve, 24V, 10mm Orifice, PA66 and 316 Stainless Steel Body 8256000.8001.02400
Specifications
| Country of Origin | Germany |
|---|---|
| Brand | Buschjost |
| Body Material | PA66, 316 Stainless Steel |
| Maximum Operating Pressure | 10 bar |
| Inlet Connection Type | Threaded |
| Series | 82560/82570 |
| Number Of Ports | 2 |
| Maximum Operating Temperature | 50°C |
| Minimum Operating Temperature | -10°C |
| Orifice Diameter | 10mm |
| Supply Voltage | 24V |
| Hazardous Area Certification | x II 2 GD EEx me II T3 |
| Default Valve Position | NC |
| Flow Factor Kv | 1.5m³/h |
| Buschjost Solenoid Valve 8273000.9101.02400, 2 Port, NC, 24V dcBrand | Buschjost |
Key Features
- The valve has a 10mm orifice diameter for efficient flow control.
- Constructed with PA66 and 316 stainless steel body materials ensuring durability and chemical resistance.
- Suitable for operation within -10°C to 50°C temperature range.
- Capable of handling maximum operating pressure of 10 bar.
- Electromagnetic operation with forced lift and servo assist for precise control.
- Conforms to standards including PED 97/23/EG Art. 3 § 3 and EN 60529 IP65.
- Designed for use in industrial, fluid power, and pneumatic applications.
- Features a normally closed valve position with threaded inlet and outlet connections.
Product Description
Buschjost 8256000.8001.02400 is a robust 2 port normally closed (NC) solenoid valve operating at 24V, designed to regulate flow of slightly aggressive gases and liquids in industrial settings.
This valve features a 10mm orifice diameter allowing effective flow management, combined with a durable body made from PA66 and 316 stainless steel to resist corrosion and mechanical wear.
Operating temperature ranges from -10°C to 50°C with a maximum operating pressure of 10 bar, making it suitable for diverse fluid power and pneumatic applications including vacuum systems.
Electromagnetic operation is enhanced with forced lift and servo assist mechanisms ensuring reliable switching without minimum pressure differential. The valve maintains fixed flow direction with threaded connections for both inlet and outlet ports.
It complies with stringent standards such as PED 97/23/EG Art. 3 § 3, EN 60529 IP65 protection rating, electromagnetic guideline 2004/108/EC, DIN EN 175301-803, and DIN VDE 0580, ensuring high safety and performance levels.
Additionally, the valve is certified for hazardous area operation under x II 2 GD EEx me II T3, making it suitable for installation in environments with potentially explosive atmospheres.
The valve is part of the reliable and widely used IMI Buschjost 82560/82570 series. Applications span industrial automation, fluid control systems, gas and liquid handling, and HVAC industrial processes. Its membrane valve design permits use with partially aggressive fluids while ensuring vacuum compatibility.
The valve's normally closed operation provides safety and control in process automation. Package includes 1 Pc Buschjost 8256000.8001.02400 2-port solenoid valve. Explore more Solenoid Valves and fluid control products at EnvMart for industrial and commercial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The orifice diameter of this solenoid valve is 10mm, allowing for efficient flow control.
This model has a maximum operating pressure of 10 bar, making it suitable for various applications.
The valve can operate within a temperature range of -10°C to 50°C.
The valve is constructed from PA66 and 316 stainless steel, ensuring durability and chemical resistance.
It features threaded inlet and outlet connections for easy installation.
The valve uses electromagnetic operation with forced lift and servo assist for precise control and reliable switching.
It complies with standards including PED 97/23/EG Art. 3 § 3 and has an IP65 protection rating.
Yes, it is certified for hazardous area operation under x II 2 GD EEx me II T3, suitable for potentially explosive atmospheres.
This valve is part of the Buschjost 82560/82570 series, known for its reliability in industrial applications.
The default valve position is normally closed (NC), which provides safety and control in process automation.
It is suitable for industrial automation, fluid control systems, gas and liquid handling, and HVAC industrial processes.
The flow factor Kv for this valve is 1.5 m³/h, indicating its flow capacity.
