Samtec FTSH Series Straight Surface Pin Header 16 Contact 1.27 mm Pitch 2 Row Unshrouded FTSH-108-04-L-DH-A-TR

Samtec FTSH-108-04-L-DH-A-TR is a high-quality micro pin header designed for board-to-board connections in electronic assemblies. With 16 male contacts arranged in 2 rows at a 1.27 mm pitch, it provides a compact and reliable interconnect option for complex PCB designs.

The housing is made from black liquid crystal polymer, offering excellent insulation and resistance to heat and chemicals, supporting operation from -55°C up to 125°C. Contacts are constructed from phosphor bronze with gold plating, ensuring superior electrical conductivity and corrosion resistance.

This unshrouded, straight surface mount header supports a current of up to 3.4A per pin, making it suitable for demanding power and signal applications. The solder termination type assures secure attachment to circuit boards, enhancing overall assembly integrity and durability.

Samtec's FTSH series is known for extended product life, guaranteed by passing stringent mixed flowing gas tests and achieving high mating cycle counts between 250 to 2,500 cycles, ensuring reliability in industrial and electronic manufacturing contexts.

Applications range from industrial electronics, telecommunications equipment, and instrumentation to general-purpose PCB connector needs where durability, performance, and precision are critical.

This pin header features a 1.27 mm pitch for compact, high-density applications. Designed with liquid crystal polymer housing for enhanced durability and thermal stability. Contact material is phosphor bronze with gold plating to ensure excellent conductivity and resistance to corrosion.

Supports a current rating of 3.4A per pin for efficient power handling. Has 2 rows and is unshrouded, with a straight orientation suitable for surface mounting. Operates reliably across a wide temperature range from -55°C to 125°C.

Termination is via solder to provide robust mechanical and electrical connection. Ideal for industrial and electronic board assembly applications requiring reliable and long-lasting connectors. Browse the Electronics Components → PCB Headers category at EnvMart for more options from Samtec and top connector brands.
