TE Connectivity AMPMODU Series Straight Through Hole PCB Socket, 14-Contact, 2 Row, 2 mm Pitch, 650V, 12A 1-2314822-4

TE Connectivity 1-2314822-4 AMPMODU Series Straight Through Hole PCB Socket provides a high-performance, 14-contact, 2-row receptacle with a 2 mm pitch designed for reliable board-to-board interconnections. It offers a 650V voltage rating and supports currents up to 12A, making it suitable for demanding industrial and electronic applications.

The socket is constructed with a robust liquid crystal polymer housing which ensures environmental resistance and mechanical stability. The female contacts are made from bronze and are nickel and tin plated to enhance corrosion resistance and electrical performance. This model supports through-hole mounting and straight orientation for straightforward integration into printed circuit boards with various thicknesses ranging from 1.6mm to 2.4mm.

Operating temperature ranges from a minimum of -65°C up to a maximum of 105°C, allowing this component to be used in harsh industrial environments. The design features dual beam receptacle contacts to maintain two-point electrical stability ensuring secure and reliable connections. The AMPMODU series occupies 38% less PCB space compared with traditional 2.54mm centerline connectors, enabling more compact product designs.

It complies with environmental standards as halogen free and low halogen materials are used in its construction, aligning with current global regulations for safer electronics manufacturing.

This PCB socket is ideal for use in PLCs, servo drives, industrial controls, material handling equipment, instrumentation, and test devices. It supports precise and durable electrical connections in industrial automation and electronic manufacturing settings.

This PCB socket features a liquid crystal polymer housing for durability. It supports through-hole mounting and straight orientation for ease of assembly. The contacts are female, made of bronze with nickel and tin plating for corrosion resistance.

Designed to operate in temperature ranges from -65°C to 105°C. Offers reliable two-point electrical stability for secure board-to-board connection. Environmental compliance includes halogen free and low halogen materials.

Suitable for industrial automation, instrumentation, and test equipment applications. Series: AMPMODU with board-to-board connector system. Explore the Electronics Components category on EnvMart for more TE Connectivity products and similar PCB Sockets designed for industrial and electronics engineering applications.
