KEMET R76_125C Film Capacitor 820 pF ±5% 2kV DC 700V AC Through Hole R76UI082050H4J
Specifications
| Country of Origin | China |
|---|---|
| Capacitance Range | 100 pF - 15 μF |
| Brand | KEMET |
| Height | 10mm |
| Length | 18mm |
| Model | R76UI082050H4J |
| Packaging | Bag |
| Width | 4mm |
| Mount Type | Through Hole |
| Series | R76_125C |
| Maximum Operating Temperature | 125°C |
| Tolerance | ±5 % |
| Capacitance | 820pF |
| Minimum Operating Temperature | -55°C |
| Terminal type | Solder |
| Dissipation Factor | 0.1% |
| Lead Length | 25mm |
| Standards/Approvals | RoHS, IEC 60286-2 |
| Pin Count | 2 |
| Rated AC Voltage | 700V ac |
| Rated DC Voltage | 2kV dc |
| Lead Pitch | 15mm |
| Lead Diameter | 0.8mm |
| Automotive Standard | AEC-Q200 |
| Capacitance tolerance | ±2.5%, ±5%, ±10% |
| Lead Spacing | 10 mm - 37.5 mm |
| Equivalent Series Resistance ESR | 776mΩ |
Key Features
- Rated for 2 kV DC and 700 V AC voltages providing robust performance.
- Constructed with polypropylene and double metallized polyester films for enhanced durability.
- Designed for through hole mounting with 15 mm lead pitch and 25 mm lead length.
- Operates reliably between -55°C and 125°C in harsh environments.
- Features solder terminals and complies with RoHS and IEC 60286-2 standards.
- Ideal for high frequency, high current, and snubber circuit applications.
- Incorporates lead-free terminations and self-healing properties.
- Compact dimensions of 18 mm length, 10 mm height, and 4 mm width for versatile PCB layouts.
Product Description
KEMET R76UI082050H4J Film Capacitor is a high-quality passive component designed for electronics requiring stable capacitance and high voltage tolerance. With a capacitance of 820 pF and ±5% tolerance, this film capacitor supports a rated DC voltage of 2 kV and an AC voltage of 700 V, making it suitable for demanding high-frequency circuitry.
The capacitor is constructed using polypropylene film and double metallized polyester electrodes, ensuring durability and reliable electrical performance. Its radial leads are made of tinned wire, electrically welded to the capacitor core and encapsulated in a self-extinguishing, solvent-resistant plastic casing with thermosetting resin.
Featuring through hole mounting with a lead pitch of 15 mm and lead length of 25 mm, it provides secure and easy PCB installation. The component measures 18 mm in length, 10 mm in height, and 4 mm in width with a 0.8 mm lead diameter, supporting compact design requirements.
Operating within a temperature range of -55°C to 125°C, this film capacitor is well suited for harsh environments and applications requiring high reliability. It complies with RoHS and IEC 60286-2 standards, and meets the automotive AEC-Q200 qualification, making it ideal for automotive and industrial electronics.
Rated DC voltage: 2kV dc. Rated AC voltage: 700V ac. Capacitance tolerance ±5%. Equivalent series resistance (ESR) of 776 mOhms and dissipation factor of 0.1%. Lead pitch 15 mm and lead length 25 mm for through hole mounting.
Compact form factor with dimensions 18 x 10 x 4 mm. Automotive grade AEC-Q200 compliance. Self-healing properties enhance operational longevity. Applications include resonant circuits, snubbers, SCR and IGBT commutation, and high voltage/high current environments.
This Film Capacitor is widely used in industrial, automotive, and electronic manufacturing applications requiring stable and reliable performance under demanding electrical conditions. Its design supports high-frequency operation and high current capability, making it a versatile choice for engineers and manufacturers.
Explore more quality capacitors and electronic components through EnvMart's extensive catalog, supporting various industrial and commercial needs.
