Amphenol Limited MIL Spec Circular Connector Copper Alloy Straight 12 Way 700V 22A Shell Size 14 62GB-57A14-12SN

Amphenol Limited 62GB-57A14-12SN is a MIL Spec Circular Connector designed for demanding electronic component applications in industrial, military, aerospace, and harsh environment uses. It features a copper alloy construction with gold-plated male contacts and a female connector form factor that meets military standard MIL-DTL-26482, ensuring high durability and reliable electrical performance.

Operating at a voltage rating of 700V and a current capacity of 22A, this 12-contact connector utilizes a shell size 14 aluminum shell for mechanical robustness. Its straight orientation and bayonet mating type allow secure and straightforward connectivity. The connector termination is via crimp contacts, supported by an integrated neoprene rear wire sealing grommet to provide a liquid-tight and resilient sealing solution.

The operating temperature range from -55°C to 125°C makes this connector suitable for extreme temperature applications ranging from cold outdoor environments to high-heat machinery. Wire compatibility extends from 24 to 8 AWG sizes, with current carrying capabilities up to 45A, providing flexible installation options and ensuring electrical safety and performance standards in professional electrical, aerospace, and military setups.

The product originates from the United Kingdom and is intended for electronic components power & connectors applications, especially where MIL-Spec compliance and reliability under harsh conditions are critical. This connector supports critical industrial, defense, aerospace, and manufacturing use cases requiring secure and dependable circular connectors.

The connector supports a keyway orientation to reduce mismating among multiple connectors. Aluminium shell with optional brass or stainless steel variants ensures mechanical strength. Gold plating on contacts offers excellent corrosion resistance and conductivity.

Neoprene insulator and rear sealing grommet provide liquid-tight protection. Meets MIL-DTL-26482 military standard for circular connectors. Suitable for harsh environmental conditions with wide temperature operating range.

Bayonet mating provides quick locking and unlocking capability. Compatible with 24 to 8 AWG wires for diverse wiring needs.

This Amphenol Mil Spec Circular Connector is ideal for applications requiring rugged, high-quality, and reliable circular connections in electronic and power connectors industry segments. Explore more high-performance connectors and related components in EnvMart’s Electronics & Electricals catalog.
