KEMET SPST Through Hole Reed Switch 500 mA 140 V AC TRS5-100BLRU
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | KEMET |
| Length | 5mm |
| Model | TRS5-100BLRU |
| Depth | 20mm |
| Width | 8.2mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | TRS |
| Maximum Switching Current | 500mA |
| Maximum Operating Temperature | 130°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Cable |
| Contact Resistance | 150mΩ |
| Maximum Switching Power | 50W |
| Standards/Approvals | UL, RoHS, CSA, REACH |
| Maximum Switching Voltage | 140V ac |
Key Features
- The switch features SPST contact configuration for single pole single throw functionality.
- Maximum switching current is 500 milliamps, suitable for low power circuits.
- Maximum switching power rated at 50 watts ensures efficient operation in small loads.
- Constructed with nickel iron alloy contact material providing durability and corrosion resistance.
- Terminal type is cable with through hole mount ensuring easy PCB integration.
- Operates within a wide temperature range from -20°C to 130°C for diverse environments.
- Compact dimensions with 8.2 mm width, 5 mm length, and 20 mm depth allow space-saving installations.
- Compliant with UL, RoHS, CSA, and REACH standards ensuring safety and environmental compliance.
Product Description
KEMET TRS5-100BLRU SPST Through Hole Reed Switch supports maximum switching current of 500 mA and a voltage rating of 140 V AC for reliable switching in electronic circuits. This reed switch type offers single pole single throw contact configuration, ideal for on/off applications requiring small current switching.
The use of nickel iron alloy material for contacts ensures excellent corrosion resistance and long operational life under repeated operations. The switch is designed for through hole mounting and features cable-type terminals compatible with standard PCB assembly methods.
Its compact size, measuring 8.2 mm width, 5 mm length, and 20 mm depth, allows for integration into constrained circuit boards.
Operating temperature ranges from -20°C up to 130°C, making it suitable for various industrial and electronic applications including temperature detection, overheat monitoring, and control of small electric appliances.
Certified with widely recognized standards UL, RoHS, CSA, and REACH, this component complies with global safety and environmental regulations. The switch is dust, explosion, and corrosion proof providing durability in harsh environments.
Its compact design provides excellent temperature accuracy with ±2.5°C tolerance. Typical industrial applications include monitoring temperature in rice cookers, air conditioners, vending machines, copying machines, and automotive fan controls.
Manufactured in Japan, this KEMET reed switch combines high reliability and ease of use for various electronic and electrical applications. Explore similar components and switches within the Reed Switch category on EnvMart for an extensive selection of electrical switching solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current of this model is 500 mA, making it suitable for low power circuits.
This reed switch has a maximum voltage rating of 140 V AC, allowing it to operate effectively in electronic circuits.
It features an SPST (Single Pole Single Throw) contact configuration, which is ideal for on/off applications.
The contacts are made from nickel iron alloy, providing corrosion resistance and durability.
The dimensions are 8.2 mm in width, 5 mm in length, and 20 mm in depth, allowing for compact installations.
It operates within a temperature range of -20°C to 130°C, suitable for various environmental conditions.
This model is designed for through hole mounting, ensuring easy integration into printed circuit boards (PCBs).
The maximum switching power is rated at 50 watts, ensuring efficient operation in small loads.
It is compliant with UL, RoHS, CSA, and REACH standards, ensuring safety and environmental compliance.
The switch features cable-type terminals, which are compatible with standard PCB assembly methods.
Typical applications include monitoring temperature in devices like rice cookers, air conditioners, and automotive fan controls.
This model is manufactured in Japan, ensuring adherence to quality standards.
