KEMET SPST Through Hole Reed Switch 500 mA 140 V ac TRS5-95BLRU

KEMET TRS5-95BLRU SPST Through Hole Reed Switch offers high reliability for on/off operations with a contact configuration of SPST (single pole single throw). Designed for high-speed response, this reed switch supports a maximum switching current of 500 mA and a switching power of 50 W, making it suitable for compact electrical switching applications.

The device features nickel iron alloy contact material that ensures low contact resistance of 150 mΩ and excellent operational life. It is built for environmental durability, being dust, explosion, and corrosion-proof, and capable of operating across a wide temperature range from -10°C to 130°C with a temperature accuracy of ±2.5°C.

Physical dimensions are compact at 8.2 mm width, 50 mm length, and 20 mm depth. The through hole mounting with cable terminal type simplifies installation in various electronic assemblies.

Typical applications for the TRS5-95BLRU include temperature detection and overheat monitoring in electric appliances, heat-retention heater control for rice cookers, defrost systems for air conditioners and vending machines, roll heater temperature control in copying machines, and radiator water temperature detection for automotive electric fan control.

Features single pole single throw (SPST) contact configuration. Maximum switching current of 500 mA and switching power of 50 W. Contact resistance rated at 150 mΩ with nickel iron alloy contacts. Through hole mount type with cable terminal.

Operational temperature range from -10°C to 130°C with high temperature accuracy. Compact form factor (8.2 mm x 50 mm x 20 mm) facilitating easy integration. RoHS compliant ensuring environmentally safe manufacturing standards.

Designed for industrial, electrical, and automation applications requiring precise switching.

This product is manufactured in Japan with strict quality controls and is categorized under Reed Switches for electronics and electrical applications. Explore more switching components in the same category at EnvMart for comprehensive solutions.
