KEMET SPST Through Hole Reed Switch 270 mA 264 V ac TRS5-40BLRVU
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | KEMET |
| Length | 5mm |
| Model | TRS5-40BLRVU |
| Depth | 20mm |
| Width | 8.2mm |
| Mount Type | Through Hole |
| Contact Material | Nickel Iron Alloy |
| Series | TRS |
| Maximum Switching Current | 270mA |
| Maximum Operating Temperature | 130°C |
| Contact Configuration | SPST |
| Minimum Operating Temperature | -20°C |
| Terminal type | Cable |
| Contact Resistance | 150mΩ |
| Maximum Switching Power | 60.5W |
| Standards/Approvals | RoHS |
| Maximum Switching Voltage | 264V ac |
Key Features
- Offers high reliability for on/off operations.
- Features high-speed response and long operational life.
- Provides excellent environmental durability and temperature accuracy.
- Compact, light, and easy to handle with through hole mounting.
- Wide operating temperature range from -20°C to 130°C.
- Uses nickel iron alloy contact material for stable performance.
- Suitable for applications involving temperature detection and overheat monitoring.
- Designed for resistance to dust, explosion, and corrosion.
Product Description
KEMET TRS5-40BLRVU is a SPST through hole reed switch optimized for switching currents up to 270 mA and voltages up to 264 V ac. With a compact size of 8.2 mm width, 5 mm length, and 20 mm depth, it offers excellent performance for industrial and consumer electronic applications.
This reed switch is constructed with nickel iron alloy contacts, ensuring reliable contact resistance of 150 mΩ and high switching power of 60.5 W. It is designed to deliver high reliability for on/off operations, featuring a long operational life and high-speed response suitable for precision switching tasks.
Its robust design provides excellent environmental durability withstanding dust, explosions, and corrosion, and an operating temperature range of -20°C to 130°C, making it suitable for diverse environments.
Typical industrial and commercial applications include temperature detection, overheat monitoring of electrical appliances, heat-retention control in rice cookers, defrost cycle controls in air conditioners and vending machines, roll heater temperature regulation in copiers, and radiator water temperature sensing for automotive electric fan control systems.
The TRS5-40BLRVU is designed for through hole mounting and cable terminals, simplifying circuit integration in compact electronic devices. Offers high reliability for on/off operations. Features high-speed response and long operational life.
Provides excellent environmental durability and temperature accuracy. Compact, light, and easy to handle with through hole mounting. Wide operating temperature range from -20°C to 130°C. Uses nickel iron alloy contact material for stable performance.
Suitable for applications involving temperature detection and overheat monitoring. Designed for resistance to dust, explosion, and corrosion. Compatible for use in household appliances and automotive temperature control systems.
Explore more quality Reed Switches and related components in our Electronics & Electricals category, ideal for industrial automation and temperature control applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum switching current for the KEMET TRS5-40BLRVU is 270 mA.
This model operates within a temperature range of -20°C to 130°C.
The maximum switching voltage for the TRS5-40BLRVU is 264 V ac.
The contact resistance of this reed switch is 150 mΩ.
This unit is designed for through hole mounting.
The contacts of this switch are made from nickel iron alloy, ensuring stable performance.
The dimensions of the TRS5-40BLRVU are 5 mm in length, 8.2 mm in width, and 20 mm in depth.
It is suitable for applications such as temperature detection and overheat monitoring in various electrical appliances.
The maximum switching power for this model is 60.5 W.
Yes, the TRS5-40BLRVU complies with RoHS standards.
This switch features cable terminals for easy circuit integration.
The KEMET TRS5-40BLRVU is manufactured in Japan.
