Panasonic Surge Absorber Varistor 1000 V, Capacitance 400 pF, Clamping Voltage 1815 V, Clamping Current 100 A ERZE14A102S1
Specifications
| Country of Origin | Indonesia |
|---|---|
| Diameter | 17.5mm |
| Brand | Panasonic |
| THICKNESS | 9.5mm |
| Length | 24.5mm |
| Model | ERZE14A102S1 |
| Depth | 9.5mm |
| Packaging | Bulk |
| Series | E-S1 |
| Energy Rating | 440J |
| Maximum Operating Temperature | 125°C |
| Capacitance | 400pF |
| Minimum Operating Temperature | -40°C |
| Maximum dc Voltage | 895V dc |
| Pin Count | 2 |
| Termination Style | Straight Lead |
| Lead Pitch | 10mm |
| Maximum AC Voltage | 680V ac |
| Clamping Voltage VC | 1815V |
| Clamping Current | 100A |
| Maximum Surge Current | 7.5kA |
| Varistor Voltage | 1000 V |
Key Features
- Compact ZNR surge absorber from the E-S1 series with excellent transient absorption capability.
- Capacitance of 400 pF suitable for precise surge suppression applications.
- High clamping voltage of 1815 volts for effective overvoltage protection.
- Maximum continuous AC voltage rating of 680 V and DC voltage rating of 895 V.
- Designed to withstand surge currents up to 7.5 kA at temperatures up to 125°C.
- Constructed with straight lead termination and dimensions of 24.5 mm length and 17.5 mm diameter.
- Meets multiple international standards including IEC62368-1, UL1449, and C-UL.
- Suitable for surge protection of semiconductor devices and consumer electronic equipment.
Product Description
Panasonic ERZE14A102S1 Surge Absorber is a ZNR transient overvoltage component from the E-S1 series designed to protect electronics by absorbing high surge currents in a compact size. It features a capacitance of 400 pF and a Varistor voltage of 1000 V, making it an ideal component for safeguarding semiconductor devices such as transistors, diodes, ICs, thyristors, and triacs.
The device is rated for a clamping voltage of 1815 V with a maximum surge current handling capability of 7.5 kA, ensuring protection during transient overvoltages. Its maximum continuous AC voltage rating is 680 V, and DC voltage rating is 895 V. The absorber operates reliably within a temperature range from -40°C to 125°C, suitable for harsh industrial and commercial environments.
The product features straight lead termination for easy PCB mounting and has compact dimensions of 24.5 mm length, 17.5 mm diameter, and 9.5 mm thickness and depth. The E-S1 series offers excellent energy handling capability at elevated temperatures, enhancing durability and long-term protection.
This surge absorber complies with multiple industry standards including IEC62368-1, UL1449, C-UL, and others, ensuring quality and safety compliance for various applications.
It is widely used for surge protection in consumer electronics, communication devices, measuring instruments, controllers, gas and petroleum appliances, and other home appliances requiring robust surge defense.
Compact ZNR surge absorber from the E-S1 series with excellent transient absorption capability. Capacitance of 400 pF suitable for precise surge suppression applications. High clamping voltage of 1815 volts for effective overvoltage protection.
Maximum continuous AC and DC voltage ratings ensure reliable operation. Withstands surge currents up to 7.5 kA at temperatures up to 125°C. Designed with straight lead termination style for simple integration. Meets various international safety and performance standards.
Ideal for protecting semiconductors, consumer electronics, and industrial control equipment. Manufactured in Indonesia and supplied in bulk packaging. Explore Panasonic surge absorbers and related electronic components on EnvMart for reliable transient voltage protection solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The varistor can handle a maximum surge current of 7.5 kA.
It has a maximum continuous AC voltage rating of 680 V and a maximum DC voltage rating of 895 V.
The clamping voltage is 1815 V.
The capacitance of this model is 400 pF.
It has a length of 24.5 mm, a diameter of 17.5 mm, and a thickness of 9.5 mm.
The operating temperature range is from -40°C to 125°C.
This surge absorber features a straight lead termination style for easy PCB mounting.
It belongs to the E-S1 series.
It complies with IEC62368-1, UL1449, and C-UL standards.
The energy rating of this model is 440 J.
This surge absorber has a pin count of 2.
It is manufactured in Indonesia.
