MEAN WELL Switching Power Supply 254V AC to 264V AC Input, 120V DC 25A Output CSP-3000-400

MEAN WELL CSP-3000-400 switching power supply is designed for industrial and laboratory applications. It operates with an AC input voltage range of 254V to 264V and delivers a regulated DC output of 120V at 25A. The unit incorporates a high-efficiency active power factor correction circuit to comply with energy standards and reduce power consumption.

This model is enclosed with a single output configuration and features forced air cooling via built-in DC fans, ensuring reliable operation under maximum operating temperatures of up to 65°C. The output voltage and current can be programmed to suit diverse applications.

Protection mechanisms include safeguards against short circuits, overloads, over voltage, over temperature, and fan failures, ensuring longevity and safety of connected equipment. Remote ON/OFF control and auxiliary power outputs with power OK signaling add to operational flexibility.

The power supply supports active current sharing with up to three units (2+1), allowing aggregate power levels up to 7200W. Optional conformal coating is available for applications requiring enhanced protection against moisture and contaminants.

Dimensions of the power supply measure 278 mm in length, 177.8 mm in width, and 63.5 mm in depth. It complies with multiple safety and performance approvals including TUV BS ENEN 6681, UL 6681, IEC 6681, and EAC TP TC 004.

Built-in active PFC function for energy efficiency. Forced air cooling by internal DC fans to maintain optimal temperature. Output voltage and current programmable for application flexibility. Comprehensive protection features for safe operation.

Remote ON/OFF control and auxiliary power outputs included. Active current sharing capability for power scalability. High operational temperature tolerance up to 65°C. Conformal coating available for harsh environments. Dimensions: 278 mm (L) x 177.8 mm (W) x 63.5 mm (D).

This switching power supply is widely used in factory automation control systems, test and measurement instruments, laser equipment, UV curing devices, and burn-in facilities among others. Its robust design and versatile features make it a reliable component for demanding industrial environments.

MEAN WELL products are renowned for quality and durability, making this model a trusted choice. Explore more Switching Power Supplies and related power solutions for various applications at EnvMart.
