Samtec FTSH Series Straight Surface Pin Header 8 Contacts 1.27 mm Pitch 2 Row Unshrouded FTSH-104-01-L-DV-P-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 3.4A |
| Model | FTSH-104-01-L-DV-P-TR |
| Mount Type | Surface |
| Housing Material | Liquid Crystal Polymer |
| Contact Material | Phosphor Bronze |
| Series | FTSH |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 8 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 0.1mm |
| Mating Pin Length | 3.05mm |
Key Features
- Features a straight orientation for surface mounting on PCBs.
- Designed with phosphor bronze contact material for durability.
- Gold plating enhances corrosion resistance and electrical conductivity.
- Supports a current rating of 3.4 A for reliable power delivery.
- Constructed with liquid crystal polymer housing for high temperature tolerance.
- Operating temperature range from -55°C up to 125°C.
- Includes 0.1 mm tail pin length and 3.05 mm mating pin length for secure connections.
- Wire-to-board connector system with solder termination type.
Product Description
Samtec FTSH-104-01-L-DV-P-TR is a high-quality Straight Surface Pin Header designed for PCB applications requiring reliable electrical connections. Featuring 8 male contacts arranged in 2 rows with a 1.27 mm pitch, this pin header is ideal for wire-to-board connections in industrial, electronic, and manufacturing environments.
The contacts are made from phosphor bronze and plated with gold to ensure excellent conductivity and durability under demanding conditions. The housing is crafted from liquid crystal polymer, providing strength and stability while withstanding extreme temperatures ranging from -55°C to 125°C.
This surface mount pin header provides a solder termination type and caters to a current capacity of 3.4 A, suitable for medium power applications on printed circuit boards. Its unshrouded construction offers easy access to contacts for testing or maintenance.
This product is suitable for use in electronic assemblies, industrial control systems, communications equipment, and other applications requiring secure, hot-pluggable connections. It is compatible with various vertical and horizontal pin configurations and supports cost-saving flash gold plating technologies.
Features a straight orientation for surface mounting on PCBs. Phosphor bronze contact material enhances mechanical resilience. Gold plating ensures long-life, corrosion-resistant connectivity. Rated for 3.4 A current suitable for a wide range of applications.
Constructed of liquid crystal polymer housing for high durability. Wide operating temperature range from -55°C to 125°C. Solder termination ensures reliable electrical connection. Unshrouded design provides easy contact access.
Samtec offers a robust range of FTSH series pin headers designed to meet diverse electronics needs with quality and reliability. Find more Samtec connectors and accessories in the Electronics Components category at EnvMart for your next project or production run.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 3.4 A, making it suitable for medium power applications on printed circuit boards.
The pin header features a pitch size of 1.27 mm, which is standard for many PCB applications.
It is constructed with a liquid crystal polymer housing and features contacts made from phosphor bronze, plated with gold for enhanced conductivity and durability.
The operating temperature range is from -55°C to 125°C, allowing it to function in extreme conditions.
This model has 8 male contacts arranged in 2 rows, designed for reliable connections.
It uses a solder termination type, ensuring a secure electrical connection on PCBs.
The FTSH-104-01-L-DV-P-TR is an unshrouded pin header, providing easy access to the contacts for testing or maintenance.
The tail pin length is 0.1 mm, which is designed for secure mounting on PCBs.
It is suitable for use in electronic assemblies, industrial control systems, and communications equipment, among other applications requiring secure connections.
The housing is made of liquid crystal polymer, which provides strength and stability under high temperatures.
This pin header supports a wire-to-board connector system, making it versatile for various PCB configurations.
The country of origin for this product is India.
