Samtec TSW Series Straight Through Hole Pin Header 6 Contact 2.54 mm Pitch 1 Row Unshrouded TSW-106-23-T-S
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 550V |
| Brand | Samtec |
| Orientation | Straight |
| Current | 4.3A |
| Model | TSW-106-23-T-S |
| Mount Type | Through Hole |
| Special Features | Many options for optimizing cost and performance with platings and ruggedizing features |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | TSW |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board |
| Tail Pin Length | 2.92mm |
| Mating Pin Length | 5.84mm |
| Contact System | .025" (0.635 mm) square post |
Key Features
- Constructed with polybutylene terephthalate housing for durability.
- Features phosphor bronze contact material plated with tin for reliable connectivity.
- Supports a current rating of 4.3 A and voltage rating up to 550 V.
- Designed with a single row, straight orientation and unshrouded contact design.
- Tail pin length measures 2.92 mm and mating pin length is 5.84 mm for secure connections.
- Operates reliably between -55°C and 105°C operating temperature range.
- Mounting is via through-hole solder termination for robust assembly.
- Pin system is a .025" (0.635 mm) square post suitable for board-to-board applications.
Product Description
Samtec TSW-106-23-T-S series pin header is a high-quality, straight through hole connector with 6 contacts and a pitch of 2.54 mm. Its robust polybutylene terephthalate housing and tin-plated phosphor bronze contacts make it ideal for reliable electronic connections in industrial and commercial PCB assemblies. Rated at 4.3 A current and 550 V voltage, this component ensures durable performance across a wide temperature range from -55°C to 105°C.
This unshrouded, single-row pin header is designed for board-to-board connector systems. It features a solder termination type suitable for through-hole mounting, enhancing mechanical stability for various manufacturing applications. The pin header’s contact gender is male, with tail and mating pin lengths carefully optimized for secure engagement.
The TSW-106-23-T-S model offers many options for plating and ruggedizing, allowing users to optimize cost and performance for their specific requirements. Applications span a large variety of standard pin counts and terminal lengths, making it a versatile component for electronics manufacturing, prototyping, and repair.
Its compact size and standard 2.54 mm pitch ensure compatibility with industry-standard PCB layouts. This pin header is widely used in industrial electronics, laboratory equipment, manufacturing automation, and other electronic component integration scenarios.
Constructed with polybutylene terephthalate housing for durability. Features phosphor bronze contact material plated with tin for reliable connectivity. Supports a current rating of 4.3 A and voltage rating up to 550 V. Single-row, straight orientation, unshrouded design.
Tail and mating pin lengths are optimized for secure connections. Through-hole solder termination enhances assembly stability. Operates reliably in extreme temperatures from -55°C to 105°C. Many plating and ruggedizing options for customization.
Explore more high-quality electronic connectors and PCB components in EnvMart's Electronics & Electricals category.
Explore more products in our PCB Pin Header category.
