MEAN WELL DC/DC Converter , 48V DC Output, 5A, 33.6V - 67.2V DC Input, DIN Rail Mount, 240W, -40°C to 70°C DDR-240C-48

MEAN WELL DDR-240C-48 DC/DC Converter is a slim and robust DIN rail-mountable power supply designed for industrial and railway environments. It delivers a stable 48V DC output at 5A with a maximum output power of 240W, ensuring reliable performance under a wide range of conditions. The converter operates efficiently with an input voltage range of 33.6V to 67.2V DC, making it suitable for various DC power sources.

The unit is engineered to withstand harsh environments with a wide operating temperature range from -40°C to 70°C and complies with multiple stringent standards including EN50121-3-2, EN61000 series, EN45545-2, IEC61373, and CE certification. Its 4kV DC isolation voltage provides excellent protection against electrical interference and noise.

Its ultra-slim 40mm width design optimizes space within electrical cabinets, while the fanless structure reduces maintenance needs and enhances reliability. Additional features include an adjustable output voltage, 150% peak load capability, current sharing, and a DC OK relay contact for system monitoring.

The converter offers full protective functions, including short circuit, overload, over voltage, over heat, input reverse polarity, and under voltage protection, ensuring safe and stable operation. Installation is simplified with standard DIN rail TS-35/7.5 or 15 mounting compatibility.

Applications for the DDR-240C-48 include industrial automation, railway control systems, security and surveillance installations, communication systems, and other demanding electrical infrastructures requiring stable DC/DC conversion.

The converter supports a wide input voltage range from 33.6V to 67.2V DC. Maximum operating temperature is 70°C and minimum is -40°C, suitable for harsh environments. High efficiency of 92% minimizes energy losses. Features 4kV DC isolation voltage for enhanced electrical safety.

Compact dimensions with width 125.2mm, depth 113.5mm, and length 40mm. Complete protection against short circuit, overload, over voltage, over temperature, and reverse polarity. Fanless design ensures silent operation and low maintenance.

DIN rail mounting allows easy installation in industrial setups. Suitable for industrial, railway control, security, and communication system applications. Explore MEAN WELL products and related DC/DC Converters on EnvMart for your electronic component and power supply needs.
