Omron Multifunction DIN Rail Timer Relay 2-Contact DPDT 100-125 V DC, 100-120 V AC, 0.05-12 s Timing Range H3CR

Omron H3CR-H8L AC100-120 S multifunction DIN rail timer relay is designed for industrial and automation applications requiring precise time delay control. Featuring a timing range of 0.05 to 12 seconds adjustable via a knob, this relay supports both AC voltage supply of 100 to 120 V and DC voltage supply of 100 to 125 V, making it versatile in mixed power systems.

This timer relay is equipped with 2 DPDT (double-pole double-throw) contacts rated for 5 A, enabling safe and reliable dual-circuit switching in control panels. Its DIN rail mounting and plug-in terminal design allow for quick installation and maintenance without rewiring, significantly reducing downtime in industrial setups.

The device operates reliably within a temperature range from -10°C to 55°C and has an IP40 rated enclosure, protecting against intrusion by solid objects larger than 1mm. It features a robust build complying with multiple international approval standards such as IEC60664-1, CSA, CCC, UL, CE, EN61812-1, and Lloyds certifications.

Typical applications include conveyor sequence timing in manufacturing, motor control interlocks requiring timed delays, staged lighting or signaling in industrial plants, and testing routines needing repeatable short-duration timing. Its compact form factor with dimensions of 48 mm by 48 mm by 93 mm suits standard panel and DIN rail environments.

This relay supports multifunction timing for versatile automation control. It features a DIN rail mount for easy panel installation. Offers a switching voltage capacity up to 250 V suitable for various control circuits. Equipped with plug-in terminals for rapid replacement and maintenance.

IP40 rated enclosure provides protection against solid objects larger than 1mm. Operating temperature range from -10°C to 55°C ensures reliable industrial use. Contacts are rated at 5 A current for dual-circuit switching capabilities.

Designed to meet international standards including IEC, CSA, UL, CE, and CCC. Compact dimensions: 48 mm length, 48 mm width, and 93 mm height for space-efficient mounting. Choose Omron Timer Relays at EnvMart for dependable industrial automation. Explore our wide selection of relays and contactors for diverse electrical and control system needs.
