Omron Multifunction DIN Rail Timer Relay 2-Contact 24V AC/DC 0.05 to 12 s Time Range DPDT Switch H3CR

Omron H3CR multifunction DIN Rail Timer Relay, model H3CR-H8L AC/DC24 S, provides precise timing control with a range of 0.05 to 12 seconds. It operates on a 24 V AC or DC supply, offering versatile functionality in industrial automation systems. Designed for compactness and ease of installation, this timer relay mounts on standard DIN rails, making it ideal for control panels and electrical enclosures where space efficiency is important.

The device features two changeover (DPDT) contacts capable of switching currents up to 5 amperes at voltages up to 250 V AC. Timing adjustment is performed through a front-mounted knob, enabling quick and flexible configuration of delay times. The multifunction timer supports various timing modes, allowing effective control over machinery sequencing, motor control interlocks, and process timing.

Constructed to operate reliably between -10°C and 55°C ambient temperatures, the unit's IP40 protection rating safeguards internal components from solid particles larger than 1 millimeter, suitable for indoor use where water ingress is not expected. Plug-in crimp terminals simplify installation and maintenance by permitting removal without the need for rewiring.

Compliance with international standards such as UL, CSA, CE, CCC, and EN61812-1 ensures the product's quality and suitability for industrial environments. Typical applications include timed outputs for PLCs, automated assembly line sequence control, delay interlocks in motor control cabinets, and timing for lamps or indicators in control panels.

Compact DIN rail mount design for efficient panel integration. Dual-pole changeover contacts provide two independent circuits. Multifunctional timing modes with adjustable delay from 0.05 to 12 seconds. Accepts both 24 V AC and 24 V DC power inputs.

Rated switching voltage of 250 V AC for direct load management. Terminal connections designed for easy plug-in installation and replacement. Operating temperature range from -10°C to 55°C for versatile use environments. IP40 protection suitable for indoor electrical panel applications.

Meets multiple international certifications for safety and reliability. Ideal for industrial automation, motor control, and process timing. Explore the full range of Timer Relays on EnvMart for diverse electrical and industrial automation solutions.
