SMC Vacuum Generator for Use with PFA, Soft Nylon, Polyurethane, FEP, Nylon, Compact Pneumatic Vacuum ZH20DLA-03-04-04

Free Delivery in India | Lowest Global Shipping Charges

SMC Vacuum Generator for Use with PFA, Soft Nylon, Polyurethane, FEP, Nylon, Compact Pneumatic Vacuum ZH20DLA-03-04-04



Category Vacuum Generator Brand SMC Condition New

Specifications

Country of Origin	Japan
Brand	SMC
Model	ZH20DLA-03-04-04
For Use With	PFA, Soft Nylon, Polyurethane, FEP, Nylon
Standards/Approvals	JIS B8392-1:2012, RoHS, ISO8573-1:2010
Standards/ApprovalsJIS B8392-1	2012, RoHS, ISO8573-1:2010
JIS B8392-1	2012, RoHS, ISO8573-1:2010

Key Features

The 2.0mm nozzle delivers focused vacuum flow suitable for precision pick tasks.
Maximum vacuum of -66 kPa supplies strong suction for lightweight parts.
Flow rate of 155 l/min (ANR) supports high throughput in cyclic operations.
Operates reliably up to 50°C ambient temperature for demanding environments.
Screw-in pneumatic connections with R3/8 supply and R1/2 exhaust threads ensure secure piping.
Compatible with nylon, soft nylon, polyurethane, FEP, and PFA tubing for versatile applications.
Ideal for pick-and-place operations in electronics assembly and automated manufacturing.
Supports vacuum gripping of small machined parts in automation and conveyor systems.

Product Description

SMC ZH20DLA-03-04-04 Vacuum Generator is engineered as a compact pneumatic vacuum ejector compatible with tubing materials such as PFA, soft nylon, polyurethane, FEP, and nylon. Designed for continuous operation within industrial temperature ranges from -5°C to 50°C, this vacuum generator efficiently supplies vacuum from compressed air to facilitate component handling and pick-and-place tasks.

The device utilizes a 2.0 mm diameter nozzle that produces a focused vacuum flow, yielding a maximum vacuum pressure of -66 kPa. This ensures reliable gripping of lightweight parts in automated and electronic manufacturing environments. Its air flow rate of 155 liters per minute (ANR) supports rapid process cycles.

Featuring screw-in pneumatic connections with an R3/8 thread for supply and R1/2 thread for exhaust, the unit integrates easily into existing piping systems, offering secure and leak-resistant installation. The vacuum port accepts a range of tubing including nylon, soft nylon, polyurethane, FEP, and PFA, accommodating applications with chemical resistance requirements.

This vacuum generator is suitable for pick-and-place applications on electronics assembly lines, vacuum gripping of small machined parts in automation, and conveyor line systems where chemical resistance is important. It is supplied boxed, optionally with a mounting bracket, and without a silencer.

The 2.0 mm nozzle size allows sharp vacuum focusing for precision tasks. Maximum vacuum of -66 kPa facilitates strong suction for delicate components. High flow capacity of 155 l/min (ANR) enables efficient operation cycles.

Durable operation in environments up to 50°C. Standard thread sizes (R3/8 supply and R1/2 exhaust) support seamless integration. Compatible with multiple tubing materials including chemically resistant types. Ideal for automated manufacturing, pick-and-place, and conveyor applications.

The SMC ZH20DLA-03-04-04 Vacuum Generator is a precise and reliable solution for industrial automation tasks requiring efficient and stable vacuum generation. Explore additional Vacuum Generators and pneumatic solutions from leading brands in EnvMart’s extensive catalog.
