Hongfa Europe GMBH PCB Power Relay, 24V dc Coil, 8A Switching Current, DPDT HF115F/024-2ZS4BF(610)

Hongfa Europe GMBH HF115F/024-2ZS4BF(610) PCB Power Relay is designed for industrial and commercial electrical applications requiring reliable switching and durability.

This relay incorporates a 24V dc coil facilitating controlled switching with a maximum current rating of 8A, suitable for robust power relay functions on printed circuit boards (PCBs).

Featuring a DPDT (Double Pole Double Throw) contact configuration, the relay offers versatile circuit control capabilities. The relay's compact dimensions of 29.0 mm length, 12.7 mm width, and 15.7 mm height enable efficient PCB space utilization.

The relay supports a wide operating temperature range from -40°C up to 85°C, making it suitable for demanding environments including industrial automation, control systems, and signal conditioning applications.

Key electrical properties include a switching voltage of up to 440V AC and 300V DC, coil resistance of 1.4kΩ, and coil power consumption of just 400mW, ensuring energy-efficient operation.

The contacts are made from silver alloy, which provides excellent conductivity and resistance to wear. Its low contact resistance of 100mΩ ensures minimal voltage drop across the relay contacts.

The device meets RoHS standards, confirming its environmental friendliness and compliance with international regulations. It also features high dielectric strength of 5kV between coil and contacts and a creepage distance of 10mm, ensuring safety and insulation integrity.

Available in plastic sealed and flux-proofed options, the relay can withstand harsh environmental conditions for enhanced reliability. Compact outline dimensions of 29.0 x 12.7 x 15.7 mm for space-saving PCB mounting. DPDT contact configuration enabling flexible switching mechanisms.

Supports switching currents up to 8A and voltages up to 440V AC and 300V DC. Wide operating temperature range from -40°C to 85°C for versatile applications. Silver alloy contacts and low contact resistance provide reliable electrical performance.

Low power coil consumption of 400mW with coil resistance 1.4kΩ. High dielectric strength of 5kV and creepage distance of 10mm ensure safety and compliance. RoHS compliant and environmentally friendly product. Plastic sealed and flux-proofed versions improve environmental resistance.

This power relay is suited for use in industrial automation, control panels, power distribution systems, HVAC equipment, and other electrical protection and switching apparatus. Explore more Power Relay solutions and electrical components on EnvMart to complement your industrial and commercial electrical installation needs.
