Artesyn High-Performance 20W Isolated DC/DC Converter, 24V DC Output, 830 mA, 18-75V DC Input, Through Hole Mount ERM01H36B

Free Delivery in India | Lowest Global Shipping Charges

Artesyn High-Performance 20W Isolated DC/DC Converter, 24V DC Output, 830 mA, 18-75V DC Input, Through Hole Mount ERM01H36B

Name: Artesyn High-Performance 20W Isolated DC/DC Converter, 24V DC Output, 830 mA, 18-75V DC Input, Through Hole Mount ERM01H36B
Brand: Artesyn
SKU: 151636
Price: 972.81 USD
Availability: InStock



Category DC/DC Converter Brand Artesyn Condition New

Specifications

Country of Origin	Taiwan
Voltage	Converters / DC-DC Converters Artesyn ERM DC/DC Converter, 24V dc/ 830 mA, 75V d
Brand	Artesyn
Efficiency	88%
Length	50.8mm
Model	ERM01H36B
Depth	11mm
Width	25.4mm
Mount Type	Through Hole
Series	ERM
Maximum Operating Temperature	85°C
Package Type	Encapsulated
Minimum Operating Temperature	-40°C
Number of outputs	1
Maximum Output Power	20W
Maximum Input Voltage	75V dc
Minimum Input Voltage	18V
Output Voltage 1	24V dc
Output Current 1	830mA
Isolation Voltage	3kV dc
Input Ratio	4:1
Input Ratio4	1

Key Features

High efficiency up to 88% increases energy savings and reliability.
Wide input voltage range from 18V to 75V DC supports various power sources.
Compact encapsulated metal package with through hole mounting for robust installation.
Single output design with reinforced insulation rated at 3000 Vac rms for safety.
Operates reliably in temperatures ranging from -40°C to 85°C with suitable derating.
Includes voltage adjust, remote On/Off, undervoltage shutdown, and overload protection.
Industry-standard footprint of 50.8mm x 25.4mm x 11mm fits space-constrained layouts.
Fully encapsulated construction ensures EMI immunity and durability in harsh environments.

Product Description

Artesyn ERM01H36B is a high-performance isolated DC/DC converter module delivering 20 watts at 24V output and 830 mA. It accepts a wide input range of 18V to 75V DC, making it suitable for various industrial and railway power systems.

Designed for robust and reliable operation, this converter features an encapsulated metal housing with through hole mounting suitable for printed circuit boards. The ERM20 series footprint of 50.8mm length by 25.4mm width and 11mm height allows efficient use of space.

With reinforced insulation rated to 3000 Vac rms and an efficiency of up to 88%, the device ensures safety and energy-efficient operation in harsh conditions. It provides protection features including voltage adjustment, remote On/Off, undervoltage shutdown, overload, and short circuit protection.

Operating effectively from -40°C to 85°C ambient temperatures, the ERM01H36B is optimized for demanding railway and other transportation equipment applications. Its single-output design supports engineering applications needing isolated power conversion with high reliability.

High power density with 20W output and compact encapsulated case. Wide input voltage span enabling use in diverse DC power environments. Robust insulation and EMI immunity for rail and industrial usage. Thermally stable operation across extreme temperature ranges.

Reliable overload and short-circuit protection for safety. Through hole mounting for stable mechanical installation. Industry standard dimension and footprint for easy integration. Suitable for industrial, railway, transportation, and embedded system power applications.

The Artesyn ERM01H36B DC/DC Converter is an ideal choice for secure, efficient DC voltage conversion within industrial and transportation voltage supply systems. Explore more power supply solutions and Artesyn products on EnvMart for your project needs.
