Artesyn High Performance 20W Isolated Through Hole DC/DC Converter 15V DC, 670mA, 40-160V DC Input ERM01CC110B

Free Delivery in India | Lowest Global Shipping Charges

Artesyn High Performance 20W Isolated Through Hole DC/DC Converter 15V DC, 670mA, 40-160V DC Input ERM01CC110B

Name: Artesyn High Performance 20W Isolated Through Hole DC/DC Converter 15V DC, 670mA, 40-160V DC Input ERM01CC110B
Brand: Artesyn
SKU: 151635
Price: 1095.47 USD
Availability: InStock



Category DC/DC Converter Brand Artesyn Condition New

Specifications

Country of Origin	Taiwan
Voltage	Converters / DC-DC Converters Artesyn ERM DC/DC Converter, 15V dc/ 670 mA, 160V
Brand	Artesyn
Efficiency	86%
Length	50.8mm
Model	ERM01CC110B
Depth	11mm
Width	25.4mm
Mount Type	Through Hole
Series	ERM
Maximum Operating Temperature	85°C
Package Type	Encapsulated
Minimum Operating Temperature	-40°C
Number of outputs	2
Maximum Output Power	20W
Maximum Input Voltage	160V dc
Minimum Input Voltage	40V
Output Voltage 1	15V dc
Output Current 1	670mA
Output Voltage Adjustment Range	±14.85 V dc, ±15.15 V dc
Isolation Voltage	3kV dc
Output Current 2	0.67A
Input Ratio	4:1
Output Voltage 2	-15V dc
Input Ratio4	1

Key Features

The converter operates efficiently up to 86% with a maximum output power of 20 Watts.
Fully encapsulated metal casing with a compact footprint of 50.8 mm length and 25.4 mm width.
Provides reinforced insulation rated at 3 kV dc ensuring high safety and EMI immunity.
Operating temperature range from -40°C to 85°C allows for harsh environment use.
Features voltage adjustable output range of ±14.85 V dc to ±15.15 V dc with dual output capability.
Includes protection features such as undervoltage shutdown, overload, and short circuit protection.
Ideal for industrial, railway, transportation, and other rugged electronic system applications.

Product Description

Artesyn ERM01CC110B is a high performance 20 watt isolated DC/DC converter module with a dual output providing 15V dc at 670 mA output current. Designed primarily for railway and other transportation system applications, the module supports a wide input range of 40 to 160 V dc via through hole mounting. Its encapsulated metal package ensures durability and EMI immunity necessary for harsh industrial environments.

The compact footprint of 50.8 mm length, 25.4 mm width, and 11 mm depth allows easy integration in constrained spaces. It features reinforced insulation rated at 3kV dc, voltage adjustable output between ±14.85 V and ±15.15 V dc, and an input voltage ratio of 4:1. Its efficiency reaches up to 86%, maintaining stable operation from -40°C to 85°C ambient temperatures with derating. Protection against undervoltage shutdown, overload, and short circuit ensures reliability and longevity.

This converter module is suited for industrial electronics including railway signaling systems, communications, instrumentation, and other demanding power supply needs. It meets rigorous performance standards without external cooling due to its efficient design and encapsulation.

The converter offers a robust 20W output power for diverse DC supply applications. Wide input voltage enables operation under varying power source conditions. Metal encapsulated package offers mechanical and EMI protection.

Dual output for positive and negative voltage supply applications. Operating temperature range supports harsh and variable environmental conditions. High insulation voltage rating ensures user and equipment safety. Compact size fits modern electronic assemblies requiring isolated DC power.

Reliable electrical protections secure circuits in industrial use.

Artesyn's ERM series is recognized for its rugged performance and safety in industrial power conversion. This ERM01CC110B DC/DC converter is an ideal component for engineers designing reliable power management systems in railways and industrial electronics applications.
