Artesyn ERM DC/DC Converter 15V DC 1.33A 75V DC Input 18V Input 20W Through Hole Encapsulated ERM01C36B

Artesyn ERM01C36B is a high-performance 20 watt DC/DC converter module designed for demanding railway and transportation system applications. It provides a stable 15V DC output voltage at 1.33A output current with an input voltage range from 18V to 75V DC. The device is fully encapsulated in a metal case for robust environmental protection and EMI immunity, with reinforced insulation rated at 3000 Vac rms.

Measuring 50.8 mm in length, 25.4 mm in width, and 11 mm in depth, this compact module utilizes a through-hole mount type. Its advanced circuit topology achieves an efficiency of up to 88%, enabling reliable operation in ambient temperatures from -40°C to 85°C with appropriate derating.

The ERM01C36B offers features including voltage adjust, remote On/Off control, undervoltage shutdown, overload, and short-circuit protection enhancing safety and operational stability. Its metal encapsulation and 2 x 1 inch footprint comply with common industry standards for easy integration.

These converters are ideal for industrial power management, railway systems, transportation electronics, and other applications requiring isolated, efficient, and reliable DC power conversion under challenging conditions.

Delivers a maximum output power of 20 watts with 88% efficiency. Operates from 18V minimum to 75V maximum input voltage. Compact dimensions of 50.8mm length, 25.4mm width, and 11mm depth. Designed for high EMI immunity with reinforced 3kV isolation voltage.

Suitable for ambient temperatures ranging from -40°C to 85°C. Features advanced circuit topology meeting demanding railway and transportation applications. Includes overload, short-circuit protection, voltage adjust, remote On/Off, and undervoltage shutdown.

Metal-encapsulated module with industry-standard 2 x 1 inch footprint. Explore our DC/DC Converters category for a wide selection of industrial-grade power solutions at EnvMart.
