KEMET R46 Film Capacitor X2, ±20 %, 330 nF, 560 V dc, 275 V ac, Through Hole R46KN333040H1M
Specifications
| Country of Origin | India |
|---|---|
| Capacitance Range | 0.01 - 10 μF |
| Display | screen |
| Brand | KEMET |
| Height | 16mm |
| Length | 26.5mm |
| Model | R46KN333040H1M |
| Packaging | Bag |
| Width | 7mm |
| Mount Type | Through Hole |
| Series | R46 |
| Maximum Operating Temperature | 110°C |
| Tolerance | ±20 % |
| Capacitance | 330nF |
| Minimum Operating Temperature | -40°C |
| Climatic category | 40/110/56 |
| Terminal type | Radial |
| Dissipation Factor | 0.1% |
| Lead Length | 30mm |
| Pin Count | 2 |
| Rated AC Voltage | 275V ac |
| Rated DC Voltage | 560V dc |
| Lead Pitch | 22.5mm |
| Lead Diameter | 0.8mm |
| Suppression Class | X2 |
| Capacitance tolerance | ±20%, ±10% |
| Lead Spacing | 10.0 - 37.5 mm |
Key Features
- The R46 series capacitors are constructed of metallized polypropylene film with self-extinguishing resin encapsulation for safety.
- Capacitance is 330 nF with a tolerance of ±20 %, suitable for general electronic circuit filtering.
- Rated DC voltage is 560 V and rated AC voltage is 275 V, class X2 for suppression between line and neutral.
- Through hole radial terminal type ensures easy PCB mounting with 22.5 mm lead pitch and 30 mm lead length.
- Operating temperature ranges from -40°C to +110°C, suitable for industrial and commercial environments.
- Dissipation factor is low at 0.1 %, ensuring high efficiency and reliability.
- Designed for electromagnetic interference (EMI) suppression in power and electronic equipment.
- This capacitor is RoHS compliant, ensuring it meets environmental safety standards.
Product Description
KEMET R46KN333040H1M Film Capacitor is a high-quality, class X2 radial leaded film capacitor designed for EMI suppression in industrial and commercial electronic applications. It features a metallized polypropylene film construction encapsulated in a self-extinguishing resin for enhanced safety and durability.
With a capacitance of 330 nF and a tolerance of ±20 %, this capacitor operates at a rated DC voltage of 560 V and an AC voltage of 275 V. It is ideal for use in power supply filters, noise suppression circuits, and other electromagnetic compatibility (EMC) applications. The through hole radial terminal mount provides secure and easy installation on printed circuit boards with a lead pitch of 22.5 mm and lead length of 30 mm.
The capacitor is capable of functioning in a wide temperature range from -40°C to +110°C, making it suitable for harsh environments in industrial machines, consumer electronics, and HVAC systems. Its low dissipation factor of 0.1 % assures minimal energy loss and high operational efficiency.
Other technical features include dimensions of 26.5 mm in length, 7 mm in width, and 16 mm in height, with 0.8 mm lead diameter. This capacitor complies with RoHS environmental regulations, reflecting responsible manufacturing standards.
The R46 series capacitors have self-healing properties, enhancing their lifespan in demanding conditions. They undergo factory screening tests at 2200 VDC/1500 VAC, ensuring reliability and quality. Applications include power electronics, industrial control systems, and EMI noise reduction.
Packaging is bagged for protection during transportation and storage.
Suitable for laboratory, manufacturing, electronics assembly, and repair environments, the KEMET R46KN333040H1M capacitor is an essential component for designing compliant and reliable electronic circuits. Explore more Film Capacitors and related components in the Electronics Components category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The capacitance of this model is 330 nF with a tolerance of ±20%.
It has a rated DC voltage of 560 V and a rated AC voltage of 275 V.
The operating temperature range is from -40°C to +110°C, making it suitable for various environments.
The lead pitch is 22.5 mm, and the lead length is 30 mm, designed for easy PCB mounting.
The dissipation factor is low at 0.1%, ensuring high efficiency during operation.
It is constructed of metallized polypropylene film and encapsulated in a self-extinguishing resin for safety.
This model uses a through hole radial terminal type for secure installation on printed circuit boards.
The dimensions are 26.5 mm in length, 7 mm in width, and 16 mm in height.
Yes, it is RoHS compliant, ensuring it meets environmental safety standards.
It is suitable for power supply filters, noise suppression circuits, and electromagnetic compatibility (EMC) applications.
The climatic category is 40/110/56, indicating its operational capabilities in various conditions.
This model has 2 pins for connection.
