KEMET R46 Film Capacitor X2, ±20%, 220nF, 560V DC 275V AC, Through Hole R46KI322040H2M

KEMET R46KI322040H2M film capacitor X2 is a high-quality passive electronic component designed for EMI suppression in electronic circuits. It features a capacitance of 220nF with a tolerance of ±20%, making it suitable for precision applications. This capacitor supports a rated DC voltage of 560V and AC voltage of 275V, ensuring excellent performance under demanding voltage conditions.

The device utilizes metallized polypropylene film encapsulated in a self-extinguishing resin for enhanced safety and durability. Its through hole mounting style, radial terminal type, and 15mm lead pitch allow easy integration into various PCB layouts. With a lead length of 30mm and lead diameter of 0.6mm, it provides reliable mechanical and electrical connections.

Operating temperature ranges from -40°C to +110°C, making it suitable for industrial, automotive, and commercial applications requiring stable performance across wide environmental conditions. The capacitor carries a suppression class X2 rating, making it effective for filtering and suppressing electromagnetic interference.

The R46 series meets the climatic category 40/110/56 and undergoes rigorous factory testing at 2200 VDC and 1500 VAC to ensure product reliability. Self-healing properties improve the capacitor’s lifespan by automatically repairing minor dielectric breakdowns. Its compact size, approximately 18mm in length, 6mm in width, and 17.5mm in height, supports space-efficient designs.

Constructed of metallized polypropylene film with self-extinguishing resin coating. Rated for 275V AC and 560V DC voltages for robust operation. Radial leads with 15mm pitch and 0.6mm diameter for secure connections. Operates reliably between -40°C and +110°C temperature range.

Suppression class X2 for EMI filtering applications. Climatic category 40/110/56 assures environmental resistance. Includes 2 pins with 30mm lead length, suitable for through hole assembly. Dissipation factor of 0.1% minimizes power loss.

Compliant with industry standards and extensively factory screened.

This Film Capacitor is ideal for use in industrial electronics, HVAC equipment, power distribution, and automotive electronics where stable and reliable EMI suppression is critical. It is available packaged in bags and provides a dependable solution for circuit design engineers.
