Pyro Controle STATOP 48 Panel PID Temperature Controller 2 Output Relay 260V ac LR04815-001

Pyro Controle LR04815-001 STATOP 48 Panel PID Temperature Controller offers advanced temperature regulation capabilities with two output relays and a supply voltage up to 260V AC. Designed for panel mounting, it provides precise control using PID and fuzzy logic algorithms, enhancing process efficiency in industrial and manufacturing environments.

The controller supports thermocouple and Pt 100 Ω resistance inputs, making it versatile for a range of temperature sensing applications. Its dual LCD displays allow operators to simultaneously view measured temperatures and setpoints, facilitating effective monitoring and adjustments.

Equipped with self-adjusting PID regulation, the device ensures stable regulation adjusted automatically to process changes. The temperature ramp feature facilitates rapid temperature changes at rates up to 480 °C per minute, while the built-in timer can be programmed up to 9999 minutes for process timing.

Control outputs include 2A inverter relays alongside analogue outputs (4-20 mA and 0-10 V) and digital logic signals (0-5 V), providing multiple interfacing options for connected equipment. Installation is straightforward with robust screw terminals and panel mount design. The IP30 protection rating safeguards internal components from inadvertent contact.

This temperature controller is designed primarily for industrial applications including automation, process control, HVAC, laboratory instrumentation, and manufacturing temperature regulation. The device is manufactured in France, ensuring high build quality and reliability.

Equipped with two output relays supporting maximum current of 2A. Operates within a temperature range from -10°C to 50°C for diverse industrial settings. Features self-adjusting PID regulation mode for optimal process control.

Dual LCD displays show measurement and setpoint values for easy monitoring. Compatible with thermocouple and Pt 100 Ω resistance temperature inputs. Panel mount design with IP30 rating ensures fitting in control panels. Programmable temperature ramp from 0 to 480 °C/min and timer up to 9999 minutes.

Control outputs include inverter relay and analogue signals (4-20 mA, 0-10 V) plus logic outputs. Robust screw terminal connections for secure installation. Manufactured in France with a professional PID temperature control system.
