STMicroelectronics Operational Amplifier 8 MHz Gain Bandwidth Product, 5-Pin SOT-23 Package TSV911ILT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.3mm |
| Length | 3mm |
| Model | TSV911ILT |
| Width | 1.75mm |
| Mount Type | Surface |
| Series | TSV911 |
| Output Current | 16mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | RoHS |
| Pin Count | 5 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 5.5V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 8MHz |
| Input Bias Current | 100 pA |
| Vos - Input Offset Voltage | 3 mV |
| Slew Rate | 4.5V/μs |
| Low input offset voltage | 1.5 mV max. (A grade) |
| High output current | 35 mA |
| ESD high tolerance | 5 kV |
Key Features
- Offers low power consumption with a typical operating current of 820 μA.
- Features unity gain stability for precision amplification.
- Handles high output current up to 35 mA ensuring robust performance.
- Operates over a wide supply voltage range from 2.5 V to 5.5 V.
- Extends operational temperature from -40°C to 125°C suitable for automotive applications.
- Enables low input bias current of around 1 pA for sensitive signal processing.
- Maintains low input offset voltage, typically 1.5 mV max for A grade variants.
- Complies with RoHS standards and AEC-Q100 automotive qualification.
Product Description
The STMicroelectronics TSV911ILT operational amplifier provides an 8 MHz gain bandwidth product in a small 5-pin SOT-23 surface-mount package optimized for low voltage operation between 3 V and 5.5 V. This single-channel amplifier offers a balance of high speed and low power consumption, drawing only 820 μA typically.
Its unity gain stability and high output current up to 35 mA ensure precision and drive capability for versatile amplifier tasks. The device also features an excellent slew rate of 4.5 V/μs and ultra-low input bias current (around 1 pA typical), making it ideal for sensitive analog signal processing applications.
Supporting an operating temperature range from -40°C to 125°C and conforming to automotive standard AEC-Q100, this amplifier is suitable for demanding industrial and automotive environments. The TSV911 series is designed with robust ESD protection of 5 kV for reliable operation.
The compact 3 mm by 1.75 mm by 1.3 mm SOT-23 package simplifies board layout and supports surface-mount technology manufacturing. Its low input offset voltage (typically 1.5 mV max in A grade) and low input offset current enhance precision in measurement and control systems.
Typical applications include industrial signal conditioning, automotive sensor interfaces, data acquisition systems, and low-power portable instrumentation where size, speed, and power efficiency are critical.
Low power consumption with 820 μA typical supply current. Unity gain stable architecture for a wide variety of amplifier configurations. High output current delivering up to 35 mA drive capability. Wide supply voltage range of 2.5 V to 5.5 V enables battery and automotive use.
Extended temperature rating from -40°C to +125°C for harsh environments. Extremely low input bias current around 1 pA minimizes signal distortion. Low input offset voltage of 1.5 mV max for accurate signal amplification.
Surface-mount SOT-23 package with compact physical dimensions. Automotive grade reliability certified under AEC-Q100. Robust 5 kV ESD protection prevents damage during handling and operation. Explore the full range of STMicroelectronics Operational Amplifiers in the Op Amps category on EnvMart for precise, reliable analog signal processing solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TSV911ILT operational amplifier has a gain bandwidth product of 8 MHz.
It operates over a supply voltage range from 3 V to 5.5 V.
This amplifier can handle a high output current of up to 35 mA.
The typical operating current is 820 μA.
It operates within an extended temperature range from -40°C to 125°C.
The input bias current is around 100 pA.
The SOT-23 package dimensions are 3 mm in length, 1.75 mm in width, and 1.3 mm in height.
The input offset voltage is typically 1.5 mV max for A grade variants.
It complies with the AEC-Q100 automotive standard.
The slew rate is 4.5 V/μs.
This model uses surface mounting.
It complies with RoHS standards.
