MEAN WELL High-Efficiency 30W DC/DC Converter 12V Output, 72V Input, 2.5A Output Current, Chassis Mount RSD-30L-12

MEAN WELL RSD-30L-12 is a high-efficiency 30W DC/DC converter designed for industrial and transportation system applications. It provides a stable 12V DC output from a wide input voltage range of 18V to 72V DC. This chassis mount module features a compact 25mm low profile and is capable of operating up to 70°C ambient temperature, making it ideal for space-critical environments.

Robust build quality includes input-output isolation at 4000V DC and low ripple noise of 60mV peak-to-peak, ensuring power quality and electromagnetic compatibility. The converter integrates protections such as over-voltage input protection (13.8 to 16.2V), overload safeguard, and constant current limiting for enhanced reliability.

The RSD-30L-12 features an LED power indicator, does not require minimum load operation, and supports free air cooling due to its half-encapsulated design. It complies with EN50155 and IEC60571 railway standards, which extends its suitability to demanding transportation and industrial automation uses.

This converter is well-suited for power distribution on board-level systems, embedded industrial applications, and other environments requiring efficient DC voltage conversion with high reliability. The chassis mount design eases installation in distributed power systems while its compact size minimizes space usage.

High efficiency up to 90% for energy-saving operation. Wide input voltage 18V to 72V DC supports varied power sources. Reliable 12V output at 2.5A current rating for steady loads. 4kV DC isolation voltage reduces interference and improves safety.

Compact chassis mount form factor with 25 mm thickness. Wide operating temperature range up to 70°C ambient. LED indicator simplifies visual power status monitoring. Compliance with CE and railway-quality standards ensures product credibility.

Built-in protections including over-voltage and overload safeguard enhance device longevity. Suitable for industrial machinery, transportation, HVAC, and automation systems.

Set your power supply designs apart with MEAN WELL’s RSD-30L-12 DC/DC Converter offering dependable performance in a compact chassis mount package. Explore more converters and DC power solutions on EnvMart to empower your projects with trusted industrial-grade components.
