TE Connectivity PCB Power Relay 24V dc Coil, 12A Switching Current, SPDT RT114024
Specifications
| Country of Origin | Austria |
|---|---|
| Brand | TE Connectivity |
| Height | 15.7mm |
| Length | 29mm |
| Model | RT114024 |
| Width | 12.7mm |
| Mount Type | PCB |
| Contact Material | Silver Nickel Alloy |
| Series | RT1 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 12A |
| Terminal type | Solder |
| Standards/Approvals | cULus, VDE |
| Coil Resistance | 1.4kΩ |
| Coil Voltage | 24V dc |
| Switching AC Voltage | 400V ac |
| Coil Power | 400mW |
Key Features
- Designed for PCB mounting with solder terminals.
- Compact dimensions with 29mm length, 12.7mm width, and 15.7mm height.
- Coil power consumption of 400mW ensures low energy usage.
- Operational temperature range from -40°C to 85°C supports various environments.
- Silver nickel alloy contact material offers durability and reliable conductivity.
- Complies with cULus and VDE safety and quality standards.
- Supports switching AC voltage up to 400V AC.
- Flux-proof design with secure pinning for long-term PCB reliability.
Product Description
TE Connectivity RT114024 is a high-quality PCB Power Relay featuring a 24V dc coil voltage and a 12A switching current with SPDT contact configuration. This RT1 series relay is designed for through-hole PCB mounting with 3.5mm pinning and is flux proof, ensuring reliable operation in industrial and domestic electrical systems.
The relay measures 29mm in length, 12.7mm in width, and 15.7mm in height. It operates efficiently with a coil power of 400mW and has a coil resistance of 1.4kΩ. It maintains stable performance over a wide temperature range from -40°C to a maximum of 85°C, making it suitable for demanding environments.
The contact material is made of silver nickel alloy, providing excellent conductivity and durability. It supports switching AC voltages up to 400V AC and switching power of up to 3kVA. The solder type terminal ensures secure and efficient connection to PCB boards.
This relay conforms to industry standards including cULus and VDE approvals, ensuring safety and compliance. The RT series relays are widely used in applications such as interface circuits, automation controls, domestic electrical systems, security lighting, and heating equipment.
Manufactured in Austria, this relay is a reliable component for enhancing industrial, laboratory, commercial, and HVAC electrical solutions needing precise and durable relay switching.
Designed for PCB mounting with through-hole 3.5mm pinning and flux proof construction. SPDT contact arrangement for versatile circuit control. Robust coil and contact ratings for demanding electrical environments. Compliance with multiple international standards ensures safe integration.
Explore more Power Relay products suited for advanced electrical and automation projects in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The TE Connectivity RT114024 power relay has a switching current of 12A.
This model operates with a coil voltage of 24V dc.
The relay measures 29mm in length, 12.7mm in width, and 15.7mm in height.
It operates within a temperature range from -40°C to 85°C.
The RT114024 features a Single Pole Double Throw (SPDT) contact configuration.
The contact material is made of silver nickel alloy, which provides durability and reliable conductivity.
The coil resistance is 1.4kΩ.
This relay supports switching AC voltages up to 400V AC.
It uses solder type terminals for secure and efficient connection to PCB boards.
This relay complies with cULus and VDE safety and quality standards.
This relay is manufactured in Austria.
The coil power consumption is 400mW, ensuring low energy usage.
