NVE 4-Channel Digital Isolator 110 Mbps 2.5 kVrms 5.5V 8-Pin SOIC IL715-3E

Free Delivery in India | Lowest Global Shipping Charges

NVE 4-Channel Digital Isolator 110 Mbps 2.5 kVrms 5.5V 8-Pin SOIC IL715-3E



Category Digital Isolator ICs Brand NVE Condition New

Specifications

Country of Origin	United States
Brand	NVE
Length	10mm
Model	IL715-3E
Depth	6.2mm
Width	1.8mm
Mount Type	Surface
Series	IL
Maximum Operating Temperature	125°C
Package Type	SOIC
Minimum Operating Temperature	-40°C
Maximum input current	20μA
Number Of Channels	4
Rise Time	4ns
Supply Voltage	5.5V
Standards/Approvals	UL, IEC
Maximum Forward Voltage	7V
Number of Pins	8
Maximum Data Rate	110Mbps
Propagation Delay Time	18ns
Package Style	SOIC

Key Features

High maximum data rate of 110 Mbps supports fast digital communication.
Provides 4 channels for simultaneous digital isolation.
Offers isolation voltage rating of 2.5 kVrms for robust electrical isolation.
Compact 8-pin SOIC surface mount package for easy PCB integration.
Operating voltage of 5.5 V with low maximum input current of 20 μA.
Fast propagation delay time of 18 ns and rise time of 4 ns for minimized signal distortion.
Wide operating temperature range from -40°C to 125°C suits industrial environments.
Complies with UL and IEC standards ensuring safety and reliability.

Product Description

The NVE IL715-3E is a high-speed, 4-channel digital isolator designed for industrial, laboratory, and electronic manufacturing applications. With a maximum data rate of 110 Mbps and an isolation voltage of 2.5 kVrms, it provides secure and efficient electrical isolation of digital signals to prevent ground loops and protect sensitive circuitry.

This isolator operates at a supply voltage of 5.5V and comes in a compact 8-pin SOIC surface mount package, making it suitable for tight PCB layouts. It features low input current consumption of 20 μA which helps minimize power usage in embedded systems.

The device offers excellent timing characteristics including a propagation delay of 18 ns and a rise time of only 4 ns, ensuring signal integrity at high speeds. With an operating temperature range from -40°C to 125°C, the IL715-3E is reliable in harsh and demanding industrial environments.

The IL715-3E digital isolator complies with UL and IEC standards, providing assurance of quality and safety. Its dimensions are 10 mm in length, 6.2 mm in depth, and 1.8 mm in width, which allows easy integration in compact electronics designs.

Typical applications include industrial automation systems, data acquisition, motor control interfaces, and communication systems requiring galvanic isolation and noise immunity. High maximum data rate of 110 Mbps supports fast digital communication.

Provides 4 channels for simultaneous digital isolation. Offers isolation voltage rating of 2.5 kVrms for robust electrical isolation. Compact 8-pin SOIC surface mount package for easy PCB integration. Operating voltage of 5.5 V with low maximum input current of 20 μA.

Fast propagation delay time of 18 ns and rise time of 4 ns for minimized signal distortion. Wide operating temperature range from -40°C to 125°C suits industrial environments. Complies with UL and IEC standards ensuring safety and reliability.

Measures 10 mm length, 6.2 mm depth, and 1.8 mm width in a SOIC style package. Discover more electronic components like Digital Isolator ICs in the Electronics Components category at EnvMart.
