Panasonic PCB Power Relay 24V dc Coil 10A Switching Current SPDT ALQ1F24

Panasonic ALQ1F24 PCB Power Relay features a 24V dc coil voltage and supports a switching current of 10A with an SPDT contact configuration. This power relay from the ALQ series is designed for PCB mounting and is compact yet capable of handling high operating powers, making it suitable for demanding electrical control and automation applications.

The relay operates reliably within a wide ambient temperature range from -40°C to +85°C, providing robust performance even under harsh conditions. It is constructed with a silver alloy contact material to ensure low contact resistance of 100mΩ, contributing to efficient switching and longevity. The coil resistance is 1.4kΩ and the coil power consumption is 400mW, balancing power needs with performance.

With a switching power capacity of 30W, it supports switching DC voltages up to 30V and AC voltages up to 250V. The relay also demonstrates high surge voltage resistance up to 8000 V and a breakdown voltage of 4000 V, which offers excellent insulation and protects connected circuits against voltage spikes.

The dimensions of the relay are compact, with a length of 20mm, width of 10mm, and height of 15.6mm, making it well-suited for space-constrained PCB designs. The relay complies with RoHS and VDE standards, underscoring its quality and safety assurance. Originating from Thailand, this relay is designed for applications including refrigerators, cooking ovens, washing machines, air conditioners, motor controls, robots, and power supplies.

Compact size with high switching capacity for various equipment. Operates reliably in temperatures ranging from -40°C to 85°C. Features high surge voltage resistance up to 8000 V. Silver alloy contact material ensures low contact resistance of 100mΩ.

PCB mounting with 1.4kΩ coil resistance and coil power of 400mW. Capable of switching DC voltage up to 30V and AC voltage up to 250V. Robust design suitable for appliances, robotics, and power supplies. Meets RoHS and VDE standards for safety and compliance.

This Panasonic ALQ1F24 power relay is ideal for industrial automation, HVAC systems, manufacturing equipment, and commercial electrical applications. Its reliable switching performance and compact design make it a dependable choice for engineers and technicians requiring a durable PCB mounted relay.
